Артикул
Название
Примечание
Количество
1
A17214
LEVER
ASSEMBLY - parking brake, Includes: Ref. 2 - 4
1шт.
2
132-26
COTTER PIN
Pin, Split (Cotter), 3/32" x 3/4"
1шт.
3
95-5
WASHER,3/8" x 7/8" x .083"
- plain (5/16")
1шт.
4
L30975
AXLE PIN,7.82mm OD x 39.69mm L
PIN - parking brake to control rod
1шт.
5
13-424
BOLT,Hex, 1/4" - 20 x 1-1/2", Gr 5
Hex, 1/4"-20 x 1 1/2", G5
4шт.
6
92-4
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
4шт.
7
213-3
ADJUSTABLE CLEVIS,5/16"-24
YOKE - rod end, adjustable
2шт.
8
25-115
NUT,5/16"-24, G5
- hex (5/16"-24 NF)
2шт.
9
L26218
ROD
- parking brake (When stock is exhausted, order L47038 for service)
1шт.
9
L47038
ROD
- parking brake
1шт.
10
141-3
CLEVIS PIN,5/16" x .940"
PIN, CLEVIS, 5/16" x .940"
1шт.
11
132-7
COTTER PIN,1/16" x 3/4"
Pin, Split (Cotter), 1/16" x 3/4"
1шт.
12
L26418
BELLCRANK - parking brake, upper, Includes: Ref. 13
1шт.
13
F60721
BUSHING - bellcrank
2шт.
14
L26431
SHAFT - bellcrank pivot
1шт.
15
195-33
WASHER,1/2"
- plain () 1/2"
2шт.
16
132-48
COTTER PIN,1/8" x 1"
Pin, Split (Cotter), 1/8" x 1"
2шт.
17
L26436
BRACKET - bellcrank support, upper
1шт.
18
13-614
BOLT,Hex, 3/8" - 16 x 7/8", Gr 5, Full Thd
2шт.
19
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
2шт.
20
213-3
ADJUSTABLE CLEVIS,5/16"-24
YOKE - rod end
1шт.
21
G10928
YOKE
ROD - bellcrank to equalizer link
1шт.
22
25-155
JAM NUT,Jam, 5/16"-24, G5
- hex. jam (5/16" - 24 NF)
1шт.
23
141-3
CLEVIS PIN,5/16" x .940"
PIN, CLEVIS, 5/16" x .940"
2шт.
24
132-7
COTTER PIN,1/16" x 3/4"
Pin, Split (Cotter), 1/16" x 3/4"
2шт.
25
L25720
LINK - equalizer
1шт.
26
213-3
ADJUSTABLE CLEVIS,5/16"-24
YOKE - rod end
2шт.
27
G10928
YOKE
ROD - equalizer, Serial Range: link-bellcrank
2шт.
28
25-155
JAM NUT,Jam, 5/16"-24, G5
- hex. jam (5/16" - 24 NF)
2шт.
29
141-3
CLEVIS PIN,5/16" x .940"
PIN, CLEVIS, 5/16" x .940"
4шт.
30
132-7
COTTER PIN,1/16" x 3/4"
Pin, Split (Cotter), 1/16" x 3/4"
4шт.
31
L26428
BELLCRANK - parking brake, lower
2шт.
32
T32219
SHAFT - bellcrank pivot
1шт.
33
195-33
WASHER,1/2"
- plain () 1/2"
2шт.
34
132-28
COTTER PIN,3/32" x 1"
Pin, Split (Cotter), 3/32" x 1"
2шт.
35
213-3
ADJUSTABLE CLEVIS,5/16"-24
YOKE - rod end
1шт.
36
25-155
JAM NUT,Jam, 5/16"-24, G5
- hex. jam (5/16" - 24 NF)
1шт.
37
L26438
YOKE - bellcrank to R.H. differential brake
1шт.
38
L25736
TRUNNION - brake, R.H.
1шт.
39
213-3
ADJUSTABLE CLEVIS,5/16"-24
YOKE - rod end
1шт.
40
25-155
JAM NUT,Jam, 5/16"-24, G5
- hex., jam (5/16" - 24 NF)
1шт.
41
A30642
ROD
- bellcrank to L.H. differential brake
1шт.
42
141-3
CLEVIS PIN,5/16" x .940"
PIN, CLEVIS, 5/16" x .940"
3шт.
43
132-7
COTTER PIN,1/16" x 3/4"
Pin, Split (Cotter), 1/16" x 3/4"
3шт.
44
L25528
BELLCRANK - parking brake to L.H. differential brake, at pivot shaft
1шт.
45
126-24
WOODRUFF KEY,#15, 1/4" x 1"
1шт.
46
L25738
SHAFT
- bellcrank pivot
1шт.
47
F62093
RING, SNAP
RING - snap
2шт.
48
195-79
WASHER - plain (1-3/16")
2шт.
49
126-24
WOODRUFF KEY,#15, 1/4" x 1"
1шт.
50
L25579
SPACER -, Serial Range: bellcrank-differential
1шт.
51
L25907
TRUNNION - brake, L.H.
1шт.
52
A27686
NUT
- retaining, differential, Serial Range: rod-trunnion
2шт.
Выбрано товаров: 53
