Артикул
Название
Примечание
Количество
1
G14420
GEAR
- ring gear & pinion
1шт.
2
A38162
WHEEL (STEERING)
WHEEL - center, ring gear mtg.
1шт.
3
114-321
PREV TORQUE BOLT,Locking, 7/16"-20 x 3/4", G8, Full Thd
BOLT - 7/16 x 3/4" N.F. hex., jay-loc
12шт.
4
A30013
WASHER,11.51mm ID x 19.05mm OD x 1.59mm Thk
- 29/64 x 3/4 x 1/16"
12шт.
7
G17006
GEAR WHEEL
GEAR - pinion
3шт.
9
A37135
AXLE PIN
SHAFT - pinion gear
3шт.
10
138-141
LOCK PIN,1/4" x 1 7/8", Slotted
PIN, , Pinion shaft 1/4" x 1 7/8", Slotted
3шт.
11
A37144
SHAFT - cross, differential
1шт.
12
126-146
WOODRUFF KEY,#27, 1/4" x 2 1/8", HT
1шт.
13
A39224
WASHER
- thrust, center wheel (.089")
1шт.
13
A39225
WASHER
- thrust, center wheel (.094")
1шт.
13
A39226
WASHER
- thrust, center wheel (.099")
1шт.
13
A39227
WASHER
- thrust, center wheel (.104")
1шт.
13
A39228
WASHER
- thrust, center wheel (.109")
1шт.
13
A39229
WASHER
- thrust, center wheel (.119")
1шт.
14
A37162
WASHER
SHIM - thrust washer, center wheel (.010")
1шт.
15
A37146
GEAR WHEEL
GEAR ASSY. - side, Includes: Ref. 16
2шт.
16
A29902
PLUG
- side gear
1шт.
17
A37160
ROLLER BEARING
CONE - bearing, side gear
2шт.
18
A37151
CARRIER - differential bearing
2шт.
19
A7890
BEARING CUP,112.738 mm OD x 23.81 mm
CUP - bearing, side gear
2шт.
20
A38165
SHIM,.003" Thk
Bearing carrier .003" Thk
1шт.
20
G10719
SHIM,.005" Thk
Bearing carrier .005" Thk
1шт.
20
G10720
SHIM,.010" Thk
Bearing carrier .010" Thk
1шт.
21
G10347
O-RING,0.139" Thk x 4.984" ID, -250, Cl 5, 75 Duro
"O" RING - bearing carrier, 5 x 5-1/4 x 1/8"
2шт.
22
A38231
OIL SEAL,66.67mm ID x 85.22mm OD x 9.53mm Thk
- oil, bearing carrier
2шт.
24
A61858
BRAKE DISC
DISC ASSY. - brake, middle
6шт.
25
A32779
PLATE ASSY.
DISC ASSY. - brake, intermediate
2шт.
R13352
BRAKE
ACTUATOR ASSY. - brake, middle, Includes: Ref. 26 - 32
2шт.
26
211-19
BALL,7/8" Dia
- . 7/8" Dia
5шт.
27
A30897
SPRING
- extension
3шт.
28
A31119
LINK
- single, actuating disc
1шт.
29
A31120
LINK
- straddle, actuating disc
1шт.
30
A31121
STEP BOLT
BOLT - link, actuating disc
2шт.
31
NSS
NOT SOLD SEPARAT
DISC - actuating (Order R13352)
2шт.
32
25-156
JAM NUT,Jam, 3/8"-24, G5
- 3/8" N.F. half. hex.
2шт.
33
A37153
COVER - brake
2шт.
34
A28203
ROD
- brake pull
2шт.
35
141-6
CLEVIS PIN,1/2" x 1.360"
PIN - yoke, pull rod
2шт.
36
132-48
COTTER PIN,1/8" x 1"
Pin, Split (Cotter), 1/8" x 1"
2шт.
37
A27465
CAP
- dust, brake rod hole
2шт.
38
G49500
STUD
- cover, 1/2 x 2-13/16"
2шт.
39
A30057
STUD
- cover, 1/2 x 2"
2шт.
40
13-822
BOLT,Hex, 1/2" - 13 x 1-3/8", Gr 5, Full Thd
2шт.
41
13-824
BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5, Full Thd
2шт.
42
13-844
BOLT,Hex, 1/2" - 13 x 2-3/4", Gr 5
Hex, 1/2"-13 x 2 3/4", G5
14шт.
43
92-8
LOCK WASHER,1/2"
18шт.
44
25-118
NUT,1/2"-20, G5
- 1/2" N.F. hex.
2шт.
45
221-4
DRAIN PLUG,Sq Hd, 1/2"-14 NPTF
PLUG - pipe, 1/2" sq. hd.
2шт.
46
A27687
HARDWARE
TRUNNION - pull rod guide
2шт.
47
A27686
NUT
- pull rod adjusting
2шт.
Выбрано товаров: 51
