Артикул
Название
Примечание
Количество
1
L15280
DIPSTICK
- oil level
1шт.
2
L15281
TUBE,1.005" OD x 8.3" L
- filler and dipstick
1шт.
L42968
TRANSMISSION ASSY. - loader, Includes: Ref. 6 - 45
1шт.
6
221-654
PLUG,Hex Hd, 1/2"-14
- pipe, hex. head (1/2" NPT)
1шт.
7
221-846
PLUG,Hex Soc, 1"-11 1/2
- pipe, hex. socket head (1" NPT)
1шт.
8
221-1662
PLUG
- pipe, hex. head (1/4" NPT)
1шт.
9
13-520
BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5
HHCS - 5/16" - 19 NC x 1-1/4"
5шт.
10
92-5
LOCK WASHER,5/16"
med. sect. 5/16"
5шт.
11
L30236
RETAINER
- bearing
1шт.
12
A27089
SNAP RING,2.36mm Thk, Ext
RING - snap
3шт.
13
L32122
BOLT
- locking and sealing
4шт.
14
92-5
LOCK WASHER,5/16"
med. sect. 5/16"
4шт.
15
A14854
RETAINER - shaft bearing
1шт.
16
A14855
GASKET
- bearing retainer
1шт.
17
A14835
RING, SNAP
RING - snap, shaft
1шт.
18
A28153
RING
- snap, Serial Range: bearing-retainer
1шт.
19
A37733
BALL BEARING
BEARING - forward drive shaft
1шт.
20
A14853
GEAR
- low and reverse (35 teeth)
1шт.
21
A14850
SHAFT
- forward drive
1шт.
22
A14859
GEAR - reverse
1шт.
L30230
SHAFT
ASSEMBLY - drive, Includes: Ref. 23 - 27
1шт.
23
A27089
SNAP RING,2.36mm Thk, Ext
RING - snap
1шт.
24
NSS
NOT SOLD SEPARAT
SHAFT - drive
1шт.
25
A14858
NEEDLE BEARING,Needle, 28.56mm ID x 34.94mm OD x 19.05mm W
BEARING - needle
1шт.
26
L30233
RING, SNAP
RING - snap, bearing
1шт.
27
A31209
BALL BEARING,49.99mm ID x 89.98mm OD x 20mm W
BEARING - reverse
1шт.
29
13-514
BOLT,Hex, 5/16" - 18 x 7/8", Gr 5
(Used with A17864 bearing retainer gasket only) Hex, 5/16"-18 x 7/8", G5, Full Thd
6шт.
30
A17864
SEAL
GASKET - output shaft bearing retainer (When stock is exhausted, order 1 - L32122 for service)
6шт.
30a
L32122
BOLT
- locking and sealing
6шт.
31
A14847
RETAINER
- output shaft bearing
1шт.
32
A14848
GASKET
- output shaft bearing retainer
1шт.
33
A14849
X
SEAL - oil, output shaft
1шт.
34
G13075
BEARING, BALL
BEARING - output shaft
1шт.
35
L30336
SHAFT
ASSEMBLY - output, Includes: Ref. 36
1шт.
36
A7509
PLUG
- expansion
1шт.
37
L30470
GEAR
- countershaft
1шт.
38
A30589
PIN
- lock, shaft
1шт.
39
L32122
BOLT
- locking and sealing
4шт.
40
92-5
LOCK WASHER,5/16"
med. sect. 5/16"
4шт.
41
A14843
CAP
RETAINER - idler shaft
1шт.
42
A14844
GASKET
- retainer
1шт.
43
A14841
SHAFT
- idler gear
1шт.
44
L30471
GEAR
ASSEMBLY - idler, Includes: Ref. 45
1шт.
45
T15025
NEEDLE BEARING,Needle, 31.75mm ID x 38.11mm OD x 19.05mm W
BEARING - needle
2шт.
46
A13914
YOKE
- stub, output
1шт.
Выбрано товаров: 45
