Артикул
Название
Примечание
Количество
1
L45863
FRAME - radiator guard
1шт.
2
L26449
COVER - access, radiator
1шт.
3
A8272
SPRING - cover extension
1шт.
4
L26448
PIN - cover hinge
1шт.
5
195-12
WASHER,#10
- plain (3/16")
1шт.
6
132-7
COTTER PIN,1/16" x 3/4"
Pin, Split (Cotter), 1/16" x 3/4"
2шт.
7
13-1032
BOLT,Hex, 5/8" - 11 x 2", Gr 5
4шт.
8
195-903
WASHER
- square, beveled
4шт.
10
25-1010
NUT,5/8"-11, G5
4шт.
11
L25654
BRACKET - radiator mounting, R.H. (Not illustrated)
1шт.
12
L25655
BRACKET - radiator mounting, L.H.
1шт.
13
9635082
NUT,5/16" - 18, Gr 5
- hex. (5/16" - 18 NC)
12шт.
14
192-20
LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND
WASHER, LOCK, 5/16"
12шт.
15
195-2020
WASHER,.344" x 1" x .065"
- special
12шт.
16
L11236
BOLT
BOLT - special, flex type (Bracket mounting)
6шт.
17
14-512
BOLT,Hex, 5/16" - 24 x 3/4", Gr 5, Full Thd
6шт.
18
92-5
LOCK WASHER,5/16"
med. sect. 5/16"
6шт.
19
195-21
WASHER,5/16"
- plain () 5/16"
6шт.
20
L25662
GRILLE - radiator guard
1шт.
21
13-516
BOLT,Hex, 5/16" - 18 x 1", Gr 5
3шт.
21a
14-516
BOLT,Hex, 5/16" - 24 x 1", Gr 5, Full Thd
HHCS - 5/16" - 24NC x 1"
3шт.
22
92-5
LOCK WASHER,5/16"
med. sect. 5/16"
6шт.
23
131-607
NUT
- Tinnerman, "U" type (5/16")
3шт.
24
D25826
CAP
- radiator, 7 P.S.I.
1шт.
25
L40548
RADIATOR ASSY. - engine cooling
1шт.
26
A23655
VALVE
- radiator drain
1шт.
27
214-262
HOSE CLAMP,#44, 2.31" - 3.25", Type F Worm
CLAMP - hose
2шт.
28
L45794
RADIATOR HOSE,2.50" ID x 6.50", SAE 20R4 Class SC
Upper 2.50" ID x 6.50", SAE 20R4 Class SC
1шт.
29
214-258
HOSE CLAMP,#28, 1.31" - 2.25", Type F Worm
2шт.
30
L45810
RADIATOR HOSE,2.50" ID x 6.50", SAE 20R4 Class SC
Lower 2.50" ID x 6.50", SAE 20R4 Class SC
1шт.
31
L19442
BAFFLE - heat, lower
1шт.
32
L19440
BAFFLE - heat, upper
1шт.
Выбрано товаров: 33
