Артикул
Название
Примечание
Количество
1
L42904
VALVE
- hydraulic, backhoe control (Parts list Figure 242)
1шт.
2
13-868
BOLT,Hex, 1/2" - 13 x 4-1/4", Gr 5
3шт.
3
95-8
WASHER,1/2"
- std. wrought 1/2"
6шт.
4
92-8
LOCK WASHER,1/2"
med. sect. 1/2"
3шт.
5
218-5070
HYD CONNECTOR,3/4" - 16 Male JIC x 1-1/16" - 12 Male ORB
CONNECTOR - male, straight, Includes: Ref. 6, stabilizer cylinder hydraulics
4шт.
6
218-5008
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
SEAL - "O" ring, stabilizer cylinder hydraulics
1шт.
7
D40809
HOSE
- valve to R.H. stabilizer cylinder (33-1/2" long), hydraulics
2шт.
8
D39220
HOSE ASSY.
HOSE - valve to L.H. stabilizer cylinder (43" long), hydraulics
2шт.
9
13-536
BOLT,Hex, 5/16" - 18 x 2-1/4", Gr 5
Stabilizer cylinder hydraulics Hex, 5/16"-18 x 2 1/4", G5
2шт.
10
D33316
CLAMP
- hose, stabilizer cylinder hydraulics
2шт.
11
D33829
BUSHING
SPACER - clamp, stabilizer cylinder hydraulics
2шт.
12
95-5
WASHER,3/8" x 7/8" x .083"
- plain (5/16"), stabilizer cylinder hydraulics
2шт.
13
131-4
LOCK NUT,5/16"-18, GB
NUT - hex., lock (5/16" - 18 NC), stabilizer cylinder hydraulics
2шт.
14
D23974
ELBOW
- adjustable, 90 degrees (Closed end), stabilizer cylinder hydraulics, Includes: Ref. 15
2шт.
15
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
10-1, 90 Duro, .755" ID x .097" Thk, Stabilizer cylinder hydraulics
1шт.
16
D26361
FITTING
ELBOW - female, 90 degrees (When stock is exhausted, order L47543 for service), stabilizer cylinder hydraulics
2шт.
16
L47543
ELBOW - female, 90 degrees, stabilizer cylinder hydraulics
2шт.
17
D43621
TUBE
- valve to stabilizer cylinder, rod end, stabilizer cylinder hydraulics
2шт.
18
218-5062
HYD CONNECTOR,7/8"-14, 37 Degree x 7/8"-14, O-Ring
CONNECTOR - male, straight, stabilizer cylinder hydraulics, Includes: Ref. 19
2шт.
19
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
10-1, 90 Duro, .755" ID x .097" Thk, Stabilizer cylinder hydraulics
1шт.
20
REF
INSTRUCTION
CYLINDER - hydraulic, stabilizer (See Figure 212 and 214 for proper cylinder), stabilizer cylinder hydraulics
2шт.
21
214-269
HOSE CLAMP,#72, 4.06" - 5", Type F Worm
CLAMP - tube to cylinder, stabilizer cylinder hydraulics
2шт.
22
218-5070
HYD CONNECTOR,3/4" - 16 Male JIC x 1-1/16" - 12 Male ORB
CONNECTOR - male, straight, swing cylinder hydraulics, Includes: Ref. 23
2шт.
23
218-5008
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
SEAL - "O" ring, swing cylinder hydraulics
1шт.
24
D45558
HOSE ASSY.
HOSE - upper valve port to L.H. swing cylinder, rod end (35" long), hydraulics, Includes: Ref. 25
1шт.
25
218-5006
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
8-1, 90 Duro, .644" ID x .087" Thk, swing cylinder hydraulics
1шт.
26
D37219
HOSE
- lower valve port to R.H. swing cylinder, rod end - crossover, (30" long), hydraulics, Includes: Ref. 27
3шт.
27
218-5006
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
8-1, 90 Duro, .644" ID x .087" Thk, swing cylinder hydraulics
1шт.
28
218-5121
ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 7/8" - 14 Male ORB
- adjustable, 90 degrees (R.H. swing cylinder), hydraulics, Includes: Ref. 29
1шт.
29
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
10-1, 90 Duro, .755" ID x .097" Thk, Swing cylinder hydraulics
1шт.
30
D36934
FITTING
ELBOW - adjustable, 90 degrees (L.H. swing cylinder), hydraulics, Includes: Ref. 31
1шт.
31
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
10-1, 90 Duro, .755" ID x .097" Thk, Swing cylinder hydraulics
1шт.
32
L42801
VALVE, CHECK
RESTRICTOR - check, swing cylinder hydraulics
2шт.
33
REF
INSTRUCTION
CYLINDER - hydraulic, R.H. swing (See Figures 220 and 222 for proper cylinder)
1шт.
34
REF
INSTRUCTION
CYLINDER - hydraulic, L.H. swing (See Figures 220 and 222 for proper cylinder)
1шт.
35
L16416
HOSE ASSY.
HOSE - to backhoe valve, end inlet (41" long), inlet and outlet hydraulics
1шт.
35a
R13931
CLAMP
- hose, inlet and outlet hydraulics
1шт.
36
L16420
TUBE - to backhoe valve, end inlet, inlet and outlet hydraulics 0.39" OD x 8.0, 3.5" L
1шт.
37
218-5110
ELBOW,90 Degree Elbow, 1-5/16" - 12 Male JIC x 1-5/16" - 12 Male ORB
Adjustable, inlet and outlet hydraulics, Incl. Ref. 38 90º, 1 5/16"-12, 37º x 1 5/16"-12, O-Ring
1шт.
38
218-5010
O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro
SEAL - "O" ring, inlet and outlet hydraulics
1шт.
39
L16415
HOSE,0.75" ID x 33.50", SAE 100R2A
ASSY, ; To Backhoe Valve, Center Inlet, Inlet and Outlet Hydraulics 0.75" ID x 33.50", SAE 100R2A
1шт.
40
L26462
TUBE ASSY.
TUBE - to backhoe valve, center inlet, inlet and outlet hydraulics
1шт.
41
218-5118
ELBOW,90 Degree Elbow, 1-1/16" - 12 Male JIC x 1-5/16" - 12 Male ORB
Adjustable, inlet and outlet hydraulics, Incl. Ref. 42 90º, 1 1/16"-12, 37º x 1 5/16"-12, O-Ring
1шт.
42
218-5010
O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro
SEAL - "O" ring, inlet and outlet hydraulics
1шт.
43
L42910
ELBOW UNION
ELBOW - adjustable, 90 degrees (Special), inlet and outlet hydraulics , Inlcudes: Ref. 44
1шт.
44
218-5010
O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro
SEAL - "O" ring, inlet and outlet hydraulics
1шт.
45
D44752
HOSE
- bypass, end inlet to outlet (25" long), inlet and outlet hydraulics
1шт.
46
218-5231
ELBOW,90 Degree, 1 1/16"-12, 37 Degree x 1 1/16"-12, 37 Degree Fem Sw
Adjustable, Inlet and outlet hydraulics 90º, 1 1/16"-12, 37º x 1 1/16"-12, 37º Fem Sw
1шт.
47
D44753
FITTING
TEE - special, bypass hose to outlet, inlet and outlet hydraulics , Inlcudes: Ref. 48
1шт.
48
218-5011
O-RING,0.118" Thk x 1.475" ID, -920, Cl 6, 90 Duro
SEAL - "O" ring, inlet and outlet hydraulics
1шт.
49
L16450
TUBE - return, valve outlet to reservoir, inlet and outlet hydraulics 1.25" OD x 7.88, 4.3" L
1шт.
50
L16417
HOSE ASSY.
HOSE - return, valve outlet to reservoir (52-1/2" long), inlet and outlet hydraulics
1шт.
51
L17513
CLAMP
- hose to transmission housing, inlet and outlet hydraulics
1шт.
52
13-1012
BOLT,Hex, 5/8" - 11 x 3/4", Gr 5, Full Thd
Inlet and outlet hydraulics Hex, 5/8"-11 x 3/4", G5, Full Thd
1шт.
Выбрано товаров: 55
