Артикул
Название
Примечание
Количество
1
D45531
CONSOLE - backhoe control
1шт.
2
321-1037
DECAL - control console
1шт.
3
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
2шт.
4
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
2шт.
5
D38292
COVER PLATE
BRACKET - console mounting
1шт.
6
13-620
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd
2шт.
7
413-632
BOLT,Hex, 3/8" - 16 x 2", Gr 5
- 3/8" x 2" N.C. hex.
2шт.
8
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
4шт.
9
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
4шт.
10
L43733
COVER - backhoe control console
1шт.
11
75-58
BOLT (MACHINE),5/16" x 1/2"
RHMS - 5/16" - 18 NC x 1/2"
4шт.
12
31375
WASHER
- control lever, large
2шт.
13
D38304
HANDLE
LEVER - control, outer (R.H. boom and swing, L.H. dipper and bucket)
2шт.
14
25-1110
NUT,5/8"-18, G5
- hex. (5/8" - 18 NF)
2шт.
15
13-620
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd
4шт.
16
D38299
SUPPORT
STUD - lever pivot
2шт.
17
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
4шт.
18
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
4шт.
19
138-96
LOCK PIN,3/16" x 1", Slotted
PIN, 3/16" x 1", Slotted
2шт.
20
132-25
COTTER PIN,3/32" x 5/8"
Pin, Split (Cotter), 3/32" x 5/8"
2шт.
21
D38298
SNAP RING
Ring, Snap, 1.438", Int, #143
2шт.
22
D38297
SPHERICAL BEARING,22.23mm ID x 36.51mm OD x 19.43mm W
- pivotal ball type
2шт.
23
D38303
ADAPTER
LEVER - pivotal, R.H.
1шт.
24
D38302
ADAPTER
LEVER - pivotal, L.H.
1шт.
25
D38305
BLOCK
WEAR BLOCK - lever
2шт.
26
25-156
JAM NUT,Jam, 3/8"-24, G5
- hex., lock (3/8" -24 NF)
8шт.
27
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
4шт.
28
D38296
JOINT
- ball type
4шт.
29
L42012
ROD - connecting, dipper and swing control
2шт.
30
D45494
ROD - connecting, bucket control (Upper)
1шт.
31
D45500
LEVER - pivot, bucket control
1шт.
32
D45490
ROD - connecting, bucket control (Lower)
1шт.
33
D45493
ROD - connecting, boom control (Upper)
1шт.
34
D45499
LEVER - pivot, boom control
1шт.
35
D45491
ROD - connecting, boom control (Lower)
1шт.
36
70213
KNOB
- control lever, small (Used with D45496 and D45497 levers only)
2шт.
36
D49996
KNOB
- control lever, small (Used with L46264 levers only)
2шт.
37
D45496
LEVER
- stabilizer control, L.H. (When stock is exhausted, order L46264 lever and D49996 knob for service)
1шт.
37
L46264
LEVER - stabilizer control, L.H.
1шт.
38
D45497
SHIM KIT
- stabilizer control, R.H. (When stock is exhausted, order L46264 lever and D49996 knob for service)
1шт.
38
L46264
LEVER - stabilizer control, R.H.
1шт.
39
D30817
SHAFT
- lever pivot
1шт.
40
138-98
LOCK PIN,3/16" x 1 1/4", Slotted
PIN, 3/16" x 1 1/4", Slotted
1шт.
41
195-2097
WASHER,15/16" x 1 3/4" x .083"
- flat, steel (15/16" dia.)
1шт.
42
213-4
ADJUSTABLE CLEVIS,3/8"-24 x 2 1/2"
YOKE - connecting rod
4шт.
43
25-156
JAM NUT,Jam, 3/8"-24, G5
- hex. lock (3/8" - 24 NF)
4шт.
44
141-4
CLEVIS PIN,3/8" x 1.060"
PIN, CLEVIS, , Mounting 3/8" x 1.060"
4шт.
45
132-25
COTTER PIN,3/32" x 5/8"
Pin, Split (Cotter), 3/32" x 5/8"
4шт.
46
141-3
CLEVIS PIN,5/16" x .940"
PIN, CLEVIS, , Connecting rod mounting 5/16" x .940"
6шт.
47
132-25
COTTER PIN,3/32" x 5/8"
Pin, Split (Cotter), 3/32" x 5/8"
6шт.
