Артикул
Название
Примечание
Количество
1
D45375
CONSOLE - backhoe control
1шт.
2
321-1264
DECAL
- control console
1шт.
3
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
2шт.
4
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
2шт.
5
D38292
COVER PLATE
BRACKET - console mounting
1шт.
6
13-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd
2шт.
7
413-632
BOLT,Hex, 3/8" - 16 x 2", Gr 5
- 3/8" x 2" N.C. hex.
2шт.
8
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
4шт.
9
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
4шт.
10
L43733
COVER - backhoe control console
1шт.
11
75-58
BOLT (MACHINE),5/16" x 1/2"
RHMS - 5/16" - 18 NC x 1/2"
4шт.
12
138-98
LOCK PIN,3/16" x 1 1/4", Slotted
PIN, 3/16" x 1 1/4", Slotted
1шт.
13
D30817
SHAFT
- control levers
1шт.
14
D45371
LEVER - control, R.H. stabilizer (When stock is exhausted, order D48265 lever and 219-92 fitting for service)
1шт.
14
D48265
LEVER
- control, R.H. stabilizer (When stock is exhausted, order L46693 lever and D49996 knob for service)
1шт.
14
L46693
HANDLE
LEVER - control, R.H. stabilizer
1шт.
15
D45370
LEVER
- control, L.H. stabilizer (When stock is exhausted, order D48266 lever and 219-92 fitting for service)
1шт.
15
D48266
LEVER
- control, L.H. stabilizer (When stock is exhausted, order L46692 lever and D49996 knob for service)
1шт.
15
L46692
HANDLE
LEVER - control, L.H. stabilizer
1шт.
16
D38320
LEVER
- pivot, swing (When stock is exhausted, order D48270 lever and 219-39 fitting for service)
1шт.
16
D48270
LEVER
- pivot, swing
1шт.
17
D45369
LEVER - control, boom (When stock is exhausted, order D48267 lever and 219-92 fitting for service)
1шт.
17
D48267
LEVER
- control, boom (When stock is exhausted, order L46694 lever and D49996 knob for service)
1шт.
17
L46694
HANDLE
LEVER - control, boom
1шт.
18
D45368
LEVER - control, dipper (When stock is exhausted, order D48268 lever and 219-92 fitting for service)
1шт.
18
D48268
LEVER
- control, dipper (When stock is exhausted, order L46695 lever and D49996 knob for service)
1шт.
18
L46695
HANDLE
LEVER - control, dipper
1шт.
19
D45367
LEVER - control, bucket (When stock is exhausted, order D48269 lever and 219-92 fitting for service)
1шт.
19
D48269
LEVER
- control, bucket (When stock is exhausted, order L46696 lever and D49996 knob for service)
1шт.
19
L46696
HANDLE
LEVER - control, bucket
1шт.
19a
219-92
LUBE NIPPLE,90 Degree Elbow, 1/8" NPTF
FITTING - grease, 90 degrees (If used)
5шт.
19b
219-39
FITTING
- grease, 45 degrees (If used)
1шт.
20
195-2097
WASHER,15/16" x 1 3/4" x .083"
- flat, steel (15/16")
1шт.
21
70213
KNOB
- control lever (Used with 3/8" NF threaded lever)
5шт.
21
D49996
KNOB
- control lever (Used with 1/2" NF threaded lever)
5шт.
22
132-25
COTTER PIN,3/32" x 5/8"
Pin, Split (Cotter), 3/32" x 5/8"
6шт.
23
141-4
CLEVIS PIN,3/8" x 1.060"
PIN, CLEVIS, , Mounting 3/8" x 1.060"
6шт.
24
213-4
ADJUSTABLE CLEVIS,3/8"-24 x 2 1/2"
YOKE - connecting rod
6шт.
25
25-156
JAM NUT,Jam, 3/8"-24, G5
- hex., jam (3/8" - 24 NF)
6шт.
26
D45372
ROD - connecting, R.H. and L.H. stabilizer, boom, dipper and bucket control
5шт.
27
D38314
ROD
- connecting, swing control
1шт.
28
132-25
COTTER PIN,3/32" x 5/8"
Pin, Split (Cotter), 3/32" x 5/8"
6шт.
29
141-3
CLEVIS PIN,5/16" x .940"
PIN, CLEVIS, , Yoke mounting 5/16" x .940"
6шт.
30
132-25
COTTER PIN,3/32" x 5/8"
Pin, Split (Cotter), 3/32" x 5/8"
3шт.
31
D21762
ROD
- connecting, R.H. swing control
1шт.
32
141-4
CLEVIS PIN,3/8" x 1.060"
PIN, CLEVIS, , Mounting 3/8" x 1.060"
1шт.
33
213-4
ADJUSTABLE CLEVIS,3/8"-24 x 2 1/2"
YOKE - connecting rod
1шт.
34
25-156
JAM NUT,Jam, 3/8"-24, G5
- hex., jam (3/8" - 24 NF)
2шт.
35
D37600
YOKE
- connecting rod
1шт.
36
D30819
ROD
- connecting, L.H. swing control
1шт.
37
413-632
BOLT,Hex, 3/8" - 16 x 2", Gr 5
- 3/8" x 2" N.C. hex.
2шт.
38
D37618
SHAFT - swing pedals
1шт.
39
D37616
BRACKET - shaft
1шт.
40
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
2шт.
41
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
2шт.
42
D47224
PEDAL
- swing, R.H.
1шт.
43
D30706
BUSHING
- pedal
2шт.
44
D47225
PEDAL - swing, L.H.
1шт.
45
D30706
BUSHING
- pedal
2шт.
46
D47222
GUARD - swing pedal, R.H.
1шт.
47
D47223
GUARD - swing pedal L.H.
1шт.
47a
D47936
LINING
TRIM - pedal guard
2шт.
48
13-612
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd
4шт.
49
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
4шт.
50
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
4шт.
51
13-832
BOLT,Hex, 1/2" - 13 x 2", Gr 5
2шт.
52
92-8
LOCK WASHER,1/2"
med. sect. 1/2"
2шт.
53
25-148
JAM NUT,Jam, 1/2"-13, G5
- hex, jam (1/2"-13 NC)
2шт.
Выбрано товаров: 68
