Артикул
Название
Примечание
Количество
1
D44741
TOWER - backhoe swing, Includes: Ref. 2 and 3
1шт.
2
D30756
BUSHING,51.02mm ID x 63.5mm OD x 31.8mm L
- tower at mounting frame
2шт.
3
D33024
BUSHING,51.02mm ID x 63.5mm OD x 25.4mm L
- tower at boom cylinder
2шт.
4
D44733
PIN
BOLT - mounting, swing tower
1шт.
5
D44813
SHIM,53.34mm ID x 76.2mm OD x 0.89mm Thk
1шт.
6
D26919
SNAP RING,#200, Ext
Ring, Snap, , pin #200, Ext
1шт.
7
219-1
LUBE NIPPLE,1/8" - 27 NPTF
FITTING - grease, straight (1/8" NPT)
1шт.
8
D26919
SNAP RING,#200, Ext
Ring, Snap, , pin #200, Ext
2шт.
9
195-2155
WASHER,2 1/16" x 3" x .109"
- flat, steel (2-1/16")
2шт.
10
D33637
PIN
- tower to mounting frame
1шт.
11
219-1
LUBE NIPPLE,1/8" - 27 NPTF
FITTING - grease, straight (1/8" NPT)
1шт.
12
D44735
AXLE PIN
PIN -, Serial Range: boom-tower
1шт.
13
D45557
SHIM
-, Serial Range: boom-tower
1шт.
14
D41472
WASHER
- flat, steel (2-1/4")
2шт.
15
F40807
SNAP RING,#225, Ext
Ring, Snap, , pin #225, Ext
2шт.
16
D44693
BOOM - backhoe, Includes: Ref. 17 - 21
1шт.
17
D44688
BUSHING
- boom, at tower
2шт.
18
D44686
SPACER
- bushing, at tower
1шт.
19
D45325
BUSHING
- boom, at dipper arm
2шт.
20
D45311
SPACER
- bushing, at dipper arm
1шт.
21
D33024
BUSHING,51.02mm ID x 63.5mm OD x 25.4mm L
- boom, at cylinder anchors
4шт.
22
219-1
LUBE NIPPLE,1/8" - 27 NPTF
FITTING - grease, straight (1/8" NPT)
1шт.
23
219-55
LUBE NIPPLE,90 Degree Elbow, 1/8" - 27 NPTF
NIPPLE, LUBE, 90º, 1/8" NPT x .84" lg
1шт.
24
D26919
SNAP RING,#200, Ext
Ring, Snap, , pin #200, Ext
4шт.
25
195-2155
WASHER,2 1/16" x 3" x .109"
- flat, steel (2-1/16")
4шт.
26
D37607
PIN
- boom cylinder mounting
2шт.
27
REF
INSTRUCTION
CYLINDER - hydraulic, boom (See Figures 224 and 226 for proper cylinder)
1шт.
28
D26919
SNAP RING,#200, Ext
Ring, Snap, , pin #200, Ext
4шт.
29
195-2155
WASHER,2 1/16" x 3" x .109"
- flat, steel (2-1/16")
5шт.
30
D37607
PIN
- crowd cylinder mounting, at boom
1шт.
31
D44734
AXLE PIN
PIN - crowd cylinder mounting, at dipper arm
1шт.
32
REF
INSTRUCTION
CYLINDER - hydraulic, crowd (See Figures 228 and 230 for proper cylinder)
1шт.
33
D44649
DIPPER
ARM - backhoe (When stock is exhausted, order L47603 for service), Includes: Ref. 34 - 38
1шт.
33
L47603
BOOM
DIPPER ARM - backhoe
1шт.
34
D33024
BUSHING,51.02mm ID x 63.5mm OD x 25.4mm L
- dipper arm, at crowd cylinder
2шт.
35
D44697
BUSHING
- dipper arm, at boom
2шт.
36
D37392
BUSHING,44.68mm ID x 53.98mm OD x 31.75mm L
- dipper arm, at bucket cylinder
2шт.
37
D30741
BUSHING,38.33mm ID x 47.63mm OD x 50.8mm L
- dipper arm, at bucket link
2шт.
38
D37443
BUSHING,44.68mm ID x 57.15mm OD x 50.8mm L
- dipper arm, at bucket
2шт.
39
219-55
LUBE NIPPLE,90 Degree Elbow, 1/8" - 27 NPTF
NIPPLE, LUBE, 90º, 1/8" NPT x .84" lg
1шт.
40
D26919
SNAP RING,#200, Ext
Ring, Snap, , pin #200, Ext
2шт.
41
195-2155
WASHER,2 1/16" x 3" x .109"
- flat, steel (2-1/16")
2шт.
42
D44734
AXLE PIN
PIN - boom to dipper arm
1шт.
43
D25280
SNAP RING,#175, Ext
Ring, Snap, , pin #175, Ext
2шт.
44
195-2152
WASHER,1 13/16" x 2 1/2" x .109"
- flat, steel (1-13/16")
2шт.
45
D44742
PIN - bucket cylinder to dipper arm
1шт.
46
REF
INSTRUCTION
CYLINDER - hydraulic, bucket (See Figures 216 and 218 for proper cylinder)
1шт.
47
D25279
SNAP RING,M35, Int
RING - pin retaining
4шт.
48
D28610
WASHER,38.5mm ID x 63.5mm OD x 2.66mm Thk
- special
6шт.
49
D37612
PIN,38.1mm OD x 222.25mm L
- bucket link to bucket cylinder and dipper arm
2шт.
50
D49015
DRAG LINK
LINK - bucket cylinder to dipper arm, R.H., Includes: Ref. 51 and 52
1шт.
51
D30933
BUSHING,38.41mm ID x 47.63mm OD x 31.75mm L
- link, at bucket cylinder
1шт.
52
D32919
BUSHING,38.4mm ID x 47.63mm OD x 19.05mm L
- link, at dipper arm
1шт.
53
D49014
POWER ARM
LINK - bucket cylinder to dipper arm, L.H., Includes: Ref. 54 and 55
1шт.
54
D30933
BUSHING,38.41mm ID x 47.63mm OD x 31.75mm L
- link, at bucket cylinder
1шт.
55
D32919
BUSHING,38.4mm ID x 47.63mm OD x 19.05mm L
- link, at dipper arm
1шт.
56
D44730
LINK
- bucket cylinder to bucket, Includes: Ref. 57
2шт.
57
D30933
BUSHING,38.41mm ID x 47.63mm OD x 31.75mm L
- link
2шт.
58
D25279
SNAP RING,M35, Int
RING - pin retaining
2шт.
59
D28610
WASHER,38.5mm ID x 63.5mm OD x 2.66mm Thk
- special
2шт.
60
D30899
PIVOT PIN,38.1mm OD x 338.14mm L
PIN - bucket link to bucket (Used with D41569, D41570, D49240 and L43428 trenching buckets only)
1шт.
PIN,38mm Od x 246mm L
- bucket link to bucket (Used with all buckets except D41569, D41570, D49240 and L43428)
1шт.
D37793
PIN
- bucket link (Used with frost point installation only)
1шт.
61
D37450
SPACER,40.89mm ID x 48.26mm OD x 63.5mm L
SPACER - bucket link
1шт.
62
D25280
SNAP RING,#175, Ext
Ring, Snap, , pin #175, Ext
2шт.
63
195-2152
WASHER,1 13/16" x 2 1/2" x .109"
- flat, steel (1-13/16")
2шт.
64
D37613
PIN
- dipper arm to bucket or frost point (Used with all buckets except D37473 and D41547)
1шт.
D40244
PIN,44.45mm OD x 327.02mm L
- dipper arm to bucket (Used with D37472 and D41547 buckets only)
1шт.
65
REF
INSTRUCTION
BUCKET - backhoe (See Figures 164 - 168 for options)
1шт.
D42577
SPARE PART
FROST POINT ASSEMBLY - backhoe, Includes: Ref. 66 and 67
1шт.
66
NSS
NOT SOLD SEPARAT
SHANK - frost point
1шт.
67
D43416
POINT
- tooth
1шт.
68
D43417
PIN
FLEX PIN - point
1шт.
Выбрано товаров: 73
