Артикул
Название
Примечание
Количество
1
A19416
BALL
KNOB - control lever (When stock is exhausted, order 31375 knob for service)
1шт.
1
CAS31375
KNOB
- control lever
1шт.
2
L26384
LEVER
- control, lift and tilt
1шт.
3
L17517
SUPPORT BLOCK ASSEMBLY - control lever, Includes: Ref. 4 and 5
1шт.
4
L17421
BUSHING
- control lever pivot
2шт.
5
L17420
BUSHING
- mounting pin pivot
2шт.
6
L26385
SNAP RING,#87, Ext
Ring, Snap, #87, Ext
2шт.
7
195-45
WASHER,3/4"
1шт.
8
132-72
PIN
- cotter, 5/32" dia. x 1-3/8"
1шт.
9
L26342
ARM
- control lever to tilt link
1шт.
10
126-17
WOODRUFF KEY,#91, 1/4" x 3/4"
1шт.
11
83-44
SET SCREW,Hex Soc, 1/4"-20 x 1/4"
SCREW - set, hex. socket head (1/4" - 20 NC x 1/4") Cup point
2шт.
12
L26386
YOKE
- tilt link
1шт.
13
141-4
CLEVIS PIN,3/8" x 1.060"
PIN, CLEVIS, 3/8" x 1.060"
1шт.
14
132-27
COTTER PIN,3/32" x 7/8"
Pin, Split (Cotter), 3/32" x 7/8"
1шт.
15
25-156
JAM NUT,Jam, 3/8"-24, G5
- hex., jam (3/8" - 24 NF)
1шт.
16
L22226
ROD
END - pivotal bearing
1шт.
17
13-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd
1шт.
18
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
1шт.
19
95-6
WASHER,3/8"
- plain () 3/8"
1шт.
20
L18631
LEVER - tilt control, Includes: Ref. 21
1шт.
21
L17420
BUSHING
- tilt lever
2шт.
22
L26385
SNAP RING,#87, Ext
Ring, Snap, #87, Ext
2шт.
23
L26340
LINK - tilt control lever to valve spool
2шт.
24
141-3
CLEVIS PIN,5/16" x .940"
PIN, CLEVIS, 5/16" x .940"
2шт.
25
132-25
COTTER PIN,3/32" x 5/8"
Pin, Split (Cotter), 3/32" x 5/8"
2шт.
26
A19513
SWITCH
- actuator, neutral start (See Figure 140 for related electrical components)
1шт.
27
171-68
SCREW - machine, flat head (#6 - 32 NC x 1-1/4")
2шт.
28
195-506
WASHER,#6
- plain () Zinc plated #6
2шт.
29
129-15
NUT,#6-32
2шт.
30
L26341
DRAG LINK
LINK - lift control lever to valve spool
2шт.
31
L26373
AXLE PIN
PIN - clevis, special
2шт.
32
132-27
COTTER PIN,3/32" x 7/8"
Pin, Split (Cotter), 3/32" x 7/8"
2шт.
33
L13755
X
VALVE - loader control, 2 spool (See Figure 232 for parts list)
1шт.
34
13-672
BOLT,Hex, 3/8" - 16 x 4-1/2", Gr 5
HHCS - 3/8" - 16 NC x 4-1/2"
3шт.
35
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
3шт.
36
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
3шт.
Выбрано товаров: 37
