Артикул
Название
Примечание
Количество
L17820
SWITCH
AND KEY - electrical, Includes: Ref. 1 and 2
1шт.
1
NSS
NOT SOLD SEPARAT
SWITCH - electrical
1шт.
2
A20346
KEY
- switch, ignition
1шт.
3
L13757
HARNESS
- wiring, return-to-dig
1шт.
4
L11760
DIODE
- switch protection
1шт.
5
173-267
RHMS - #6 - 32 NC x 1-1/4"
2шт.
6
A19513
SWITCH
- actuator, neutral start
1шт.
7
195-506
WASHER,#6
- plain () Zinc plated #6
2шт.
8
129-15
NUT,#6-32
2шт.
9
L11778
CONNECTOR, ELEC
TERMINAL - electrical, bullet type
2шт.
10
REF
INSTRUCTION
VALVE - hydraulic, loader control (See Figure 232 for proper valve)
1шт.
11
13-672
BOLT,Hex, 3/8" - 16 x 4-1/2", Gr 5
HHCS - 3/8" - 16 NC x 4-1/2"
3шт.
12
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
3шт.
13
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
3шт.
14
13-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd
2шт.
15
95-6
WASHER,3/8"
- plain () 3/8"
1шт.
16
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
2шт.
17
L11541
CABLE TIE,203.2mm L, Nylon
STRAP - wire to limit switch bracket
1шт.
18
L26619
BRACKET
- limit switch box mounting
1шт.
19
49560
BAR
- limit switch box
1шт.
20
173-224
SCREW,Sl Rnd Hd, #8 - 32 x 1/4"
- machine, round head (#8 - 32 NC x 1/4") Zinc plated
2шт.
21
193-90
LOCK WASHER,Ext, #8
WASHER, LOCK, Ext, #8
2шт.
22
D40884
BOX
- limit switch mounting
1шт.
23
169-144
SCREW,Sl Fil Hd, #6 - 32 x 1 1/4"
- machine, fillister head (#6 - 32 NC x 1-1/4") Zinc plated
2шт.
24
D40921
SWITCH
- limit, return-to-dig
1шт.
25
D40924
SHIM
SPACER - switch
1шт.
26
193-89
LOCK WASHER,Ext-Int Tooth, #6
WASHER, LOCK, Ext-Int Tooth, #6
2шт.
27
129-15
NUT,#6-32
2шт.
28
D40922
COVER
- limit switch
1шт.
29
L15241
WIRE - ground (When stock is exhausted, order L40568 wire for service)
1шт.
29
L40568
WIRE - ground
1шт.
30
G45175
CLAMP
- tube, worm screw type
1шт.
31
13-640
BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5
HHCS - 3/8" - 16 NC x 2-1/2"
1шт.
32
195-25
WASHER,3/8"
1шт.
33
D40925
SPACER
SLEEVE - tube
1шт.
34
L15037
TUBE - rod support
1шт.
35
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
1шт.
36
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
1шт.
37
L13753
ROD - limit switch
1шт.
38
195-33
WASHER,1/2"
- plain () 1/2"
1шт.
39
132-25
COTTER PIN,3/32" x 5/8"
Pin, Split (Cotter), 3/32" x 5/8"
1шт.
Выбрано товаров: 41
