Запчасти Case 680CK (054) - THROTTLE CONTROL LINKAGE, USED BEFORE TRACTOR SERIAL. NO. 9103854 (10) - ENGINE

L26334

CABLE

ASSEMBLY - hand throttle, Includes: Ref. 1 - 18

1шт.

1

L32232

BOOT

- protective (Not illustrated)

1шт.

2

171-245

SCREW,Cross Flat Hd, #8 - 32 x 1/2"

- Phillips head (#8-32 NC x 1/2") Nickel plated

1шт.

3

L32233

BUTTON

- throttle release

1шт.

4

L32234

SPRING

- release button

1шт.

5

86585245

SPECIAL NUT,JAM, 5/8" - 18

- hex., jam (3/8"-24 NF) Zinc plated

2шт.

6

L32238

KNOB - throttle control

1шт.

7

L32239

ROD

- throttle release

1шт.

8

211-4

BALL

- release rod (5/32" dia.)

1шт.

9

193-68

LOCK WASHER,Int Tooth, 3/8"

WASHER, LOCK, Int Tooth, 3/8"

1шт.

10

L32235

RETAINER

- tension seal

1шт.

11

L32236

SEAL

- tension

1шт.

12

L32237

NUT - retainer, special

1шт.

13

193-61

LOCK WASHER,Int Tooth, 3/4"

WASHER, LOCK, Int Tooth, 3/4"

1шт.

14

129-168

JAM NUT,Jam, 3/4"-10, G5

- hex., jam (3/4"-16 NF)

1шт.

15

129-167

JAM NUT,Jam, 5/8"-18, G5

- hex., jam (5/8"-18 NF) Zinc plated

2шт.

16

195-541

WASHER,5/8", SAE

- plain (5/8") Zinc plated

2шт.

17

121-161

NUT - hex., jam (1/4"-28 NF) Zinc plated

1шт.

18

NSS

NOT SOLD SEPARAT

CABLE AND HOUSING - throttle

1шт.

19

L17671

COVER - throttle cable

1шт.

20

214-253

HOSE CLAMP,#10, 0.56" - 1.06", Type F Worm

CLAMP - cover to cable

1шт.

21

L26353

BRACKET - cable support

1шт.

22

13-520

BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5

HHCS - 5/16"-18 NC x 1-1/4"

2шт.

22a

95-5

WASHER,3/8" x 7/8" x .083"

- standard wrot (5/16")

2шт.

23

92-5

LOCK WASHER,5/16"

2шт.

24

9635082

NUT,5/16" - 18, Gr 5

- hex. (5/16"-18 NC)

2шт.

25

213-2

ADJUSTABLE CLEVIS,1/4"-28 x 2"

YOKE - cable to throttle arm

1шт.

26

141-2

CLEVIS PIN,1/4" x .770"

PIN - clevis

1шт.

27

RESERVED

1шт.

28

132-5

COTTER PIN,1/16" x 1/2"

Pin, Split (Cotter), 1/16" x 1/2"

1шт.

29

L26355

LEVER - linkage, hand throttle

1шт.

30

85-48

SET SCREW,Sq Hd, 1/4"-20 x 1/2"

SCREW - set, square head (1/4"-20 NC x 1/2") Cup point

1шт.

31

85-48

SET SCREW,Sq Hd, 1/4"-20 x 1/2"

SCREW - set, square head (1/4"-20 NC x 1/2") Cup point

1шт.

32

L26335

SHAFT - pivot, throttle

1шт.

33

L15114

COLLAR - throttle shaft

1шт.

34

83-44

SET SCREW,Hex Soc, 1/4"-20 x 1/4"

SCREW - set, hex. sckt. hd. (1/4"-20 NC x 1/4") Cup point

1шт.

L15113

SUPPORT ASSEMBLY - throttle linkage, Includes: Ref. 35 and 36

1шт.

35

NSS

NOT SOLD SEPARAT

SUPPORT - throttle linkage

1шт.

36

L10818

BUSHING

- support

2шт.

37

13-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd

2шт.

38

92-6

LOCK WASHER,3/8"

2шт.

39

25-106

NUT,3/8"-16, G5

- hex. (3/8"-16 NC)

2шт.

40

L26390

PEDAL - fuel shutoff

1шт.

41

T34032

VALVE SPRING

SPRING - pedal return

1шт.

42

132-89

COTTER PIN,3/16" x 3/4"

Pin, Split (Cotter), 3/16" x 3/4"

1шт.

43

95-5

WASHER,3/8" x 7/8" x .083"

- plain (5/16")

1шт.

44

132-9

COTTER PIN

PIN - cotter, 1/16" dia. x 1"

1шт.

45

L26351

PEDAL - foot accelerator (When stock is exhausted, order L26313 pedal and L12421 pad for service)

1шт.

45

L26313

PEDAL ASSY.

PEDAL - foot accelerator

1шт.

45a

L12421

PAD

- foot accelerator pedal

1шт.

46

L12427

PIN

- pivot, accelerator

1шт.

47

138-90

LOCK PIN,Sl Spring, 3/16" x 5/8", Hvy

Pin, 3/16" x 5/8", Slotted

1шт.

48

113-409

BOLT,Hex, 1/2" - 13 x 4", Gr 5

STOP BOLT - accelerator pedal (1/2"-13 NC x 4")

1шт.

49

25-158

JAM NUT,Jam, 1/2"-20, G5

- hex., jam (1/2"-13 NC)

1шт.

50

L17602

STUD - accelerator link

1шт.

51

D38296

JOINT

BALL JOINT - accelerator link

2шт.

52

25-156

JAM NUT,Jam, 3/8"-24, G5

- hex., jam (3/8"-24 NF)

4шт.

53

92-6

LOCK WASHER,3/8"

2шт.

L10824

ARM ASSEMBLY - accelerator pedal to throttle rod, Includes: Ref. 54 and 55

1шт.

54

NSS

NOT SOLD SEPARAT

ARM - pedal to throttle rod

1шт.

55

A29946

BUSHING

- arm

1шт.

56

219-8

LUBE NIPPLE,1/4" - 28 NPTF

NIPPLE, LUBE, , straight, taper, If used 1/4"-28 NPT x .54" lg

1шт.

57

L12298

ROD - throttle control

1шт.

58

141-4

CLEVIS PIN,3/8" x 1.060"

PIN, CLEVIS, , Rod to arm 3/8" x 1.060"

1шт.

59

132-27

COTTER PIN,3/32" x 7/8"

Pin, Split (Cotter), 3/32" x 7/8"

1шт.

60

L40018

ADAPTER BLOCK - throttle linkage

1шт.

61

195-28

WASHER,3/8"

- plain () 3/8"

2шт.

62

132-46

COTTER PIN,1/8" x 3/4"

Pin, Split (Cotter), 1/8" x 3/4"

1шт.

63

25-156

JAM NUT,Jam, 3/8"-24, G5

- hex., jam (3/8"-24 NF)

2шт.

64

A34709

ROD - throttle, to fuel injection pump

1шт.

48

113-409

BOLT,Hex, 1/2" - 13 x 4", Gr 5

STOP BOLT - accelerator pedal (1/2"-13 NC x 4")

1шт.
