Артикул
Название
Примечание
Количество
1
D123224
SHAFT
control levers
1шт.
2
113-66
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd
Teflon coated Hex, 1/4"-20 x 3/4", G5, Full Thd
1шт.
3
195-133
WASHER,5/16" x 3/4" x .065"
flat, black Teflon, 1/4"
1шт.
4
192-19
LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND
WASHER, LOCK, 1/4"
1шт.
5
7770
NUT,Hex, 1/4 - 20, Cl 5
1/4"-20, G5
1шт.
6
D86082
BRACKET
swing pivot, no longer used, order P/N D129392 bracket
1шт.
6a
D129392
BRACKET
swing pivot
1шт.
7
195-545
WASHER,3/4", SAE
flat, plated, 3/4", used as a shim
1шт.
8
D88212
BUSHING
SPACER left hand, not used with extendable dipper
1шт.
9
D92993
BRACKET
left hand stabilizer pivot
1шт.
10
RESERVED
1шт.
11
RESERVED
1шт.
12
RESERVED
1шт.
13
L54563
KNOB
boom, dipper, and bucket control levers
3шт.
14
D79531
LEVER
control, bucket
1шт.
15
D79530
LEVER
control, dipper
1шт.
16
D79529
LEVER
control, boom
1шт.
17
219-57
LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF
FITTING grease, 1/4" - 28 NF taper, 90°
5шт.
18
D92995
LEVER
pivot, right hand stabilizer on models without extendable dipper
1шт.
19
RESERVED
1шт.
20
D87834
LEVER
pivot, right hand stabilizer on models with extendable dipper
1шт.
21
D88213
SPACER
right hand, not used with extendable dipper
1шт.
22
213-41
ADJUSTABLE CLEVIS,3/8"-24
metal, plated, straight, Replaces fiberglass clevis on some models, used on models without extendable dipper 3/8"-24
3шт.
22a
L11182
YOKE,3/8" - 24
CLEVIS offset, 3/8", offset, used on models with extendable dipper
3шт.
23
129-123
NUT,3/8"-24, G5
3шт.
24
141-54
CLEVIS PIN,3/8" x 1 1/16"
Special length 3/8" x 1 1/16"
3шт.
25
141-53
CLEVIS PIN,5/16" x .940"
plated, special length 5/16" x .940"
3шт.
26
132-320
COTTER PIN,3/32" x 3/4"
PIN, SPLIT (COTTER), 3/32" x 3/4"
6шт.
27
D81902
ROD
boom, dipper, and bucket control, straight, models without extendable dipper
3шт.
27a
D30821
ROD
boom, dipper, and bucket control, straight, models with extendable dipper, uses offset clevis
3шт.
28
D85869
BELLOWS
BOOT rods, if used
3шт.
