Артикул
Название
Примечание
Количество
1
D90960
ARM
FRAME loader, lift, Includes: Ref. 2 - 4
1шт.
2
D37392
BUSHING,44.68mm ID x 53.98mm OD x 31.75mm L
loader frame pivot
4шт.
3
D37763
BUSHING
bucket cylinder link pivot
4шт.
4
D30931
BUSHING,38.33mm ID x 47.63mm OD x 69.85mm L
bucket mounting, orifice which this bushing fits into is P/N D5538, pivot tube
2шт.
5
219-1
LUBE NIPPLE,1/8" - 27 NPTF
FITTING grease, straight, 1/8" NPT
8шт.
6
D129819
SHAFT
pivot
1шт.
7
D62194
WASHER
flat
1шт.
8
D25280
SNAP RING,#175, Ext
Ring, Snap, #175, Ext
8шт.
9
D37611
PIVOT PIN,44.45mm OD x 255.59mm L
PIN lift, cylinder pivot
2шт.
10
D67357
PIN
lift, cylinder to frame, right hand, if used
1шт.
10a
D44881
PIN,38.1mm OD x 136.4mm L
lift, cylinder to frame, right hand, if used
1шт.
11
113-248
BOLT,Hex, 3/8" - 16 x 2-3/4", Gr 5
If used Hex, 3/8"-16 x 2 3/4", G5
2шт.
12
131-52
NUT,3/8"-16, GC
NUT hex, self locking, plated, 3/8" - 16 NC, if used
2шт.
13
113-929
BOLT,Hex, 1" - 8 x 6-1/2", Gr 5
hex head, plated, 1" - 8 NC x 6-1/2"
2шт.
14
113-927
BOLT,Hex, 1" - 8 x 5-1/2", Gr 5
hex head, plated, 1" - 8 NC x 5-1/2"
2шт.
15
D31219
BUSHING,26.67mm ID x 38.08mm OD x 101.6mm L
SPACER bushing
2шт.
16
195-553
WASHER,1", SAE
flat, plated, 1"
4шт.
17
129-110
NUT,1"-8, G5
4шт.
18
D90422
BUSHING
SPACER bushing
2шт.
19
D124047
LINK
bucket cylinder, right hand, inner, models without clam bucket, See Ref. 45, Includes: Ref. 22 - 26
1шт.
20
D124045
LINK
bucket cylinder, right hand, outer, with extra hole for antirollback rod, Includes: Ref. 22 - 26
1шт.
21
D124045
LINK
bucket cylinder, left hand, inner and outer, extra hole not used in left hand position, Includes: Ref. 22 - 26
2шт.
22
219-86
LUBE NIPPLE,1/8" NPTF
FITTING grease, straight, self tapping, 1/8" pipe, one per each link
1шт.
23
D31512
BUSHING,47.75mm ID x 57.15mm OD x 19.05mm L
one per each link
1шт.
24
D120494
DRAG LINK
LINK bucket, may Replace links without bushings on some models
2шт.
25
D30933
BUSHING,38.41mm ID x 47.63mm OD x 31.75mm L
at bucket cylinder link
2шт.
26
D30931
BUSHING,38.33mm ID x 47.63mm OD x 69.85mm L
at bucket
1шт.
27
D121194
POINTER
right hand inner link, models without clam bucket, See Ref. 48
1шт.
28
113-104
BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5
2шт.
29
192-20
LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND
WASHER, LOCK, 5/16"
2шт.
30
9635082
NUT,5/16" - 18, Gr 5
2шт.
31
D89321
PIN
bucket cylinder mounting
2шт.
32
D126717
PIN,38.1mm OD x 179.83mm L
bucket mounting, lower
2шт.
32
D126718
PIN,38.1mm OD x 179.83mm L
bucket mounting, lower - grease able
2шт.
33
D25279
SNAP RING,M35, Int
RING snap, retaining
12шт.
34
REF
INSTRUCTION
BUCKET loader, See Figure 500 for buckets
1шт.
35
D126718
PIN,38.1mm OD x 179.83mm L
bucket mounting, upper
2шт.
36
D80739
PIN
lift cylinder to frame, left hand, if used
1шт.
36a
D28649
PIN
lift cylinder to frame, left hand, if used
1шт.
37
D28610
WASHER,38.5mm ID x 63.5mm OD x 2.66mm Thk
spacer
1шт.
38
D25279
SNAP RING,M35, Int
RING snap, retaining
2-4шт.
39
D121846
STRUT
support, loader frame
1шт.
40
D121047
GROMMET
support strut
2шт.
41
L78801
AXLE PIN
PIN lock, 1/2" (13 mm) diameter
1шт.
42
G105756
CYLINDER
loader lift, See Figure 460
2шт.
43
G101186
CYLINDER
loader bucket, right hand, See Figure 462
1шт.
44
G101187
CYLINDER
loader bucket, left hand, See Figure 462
1шт.
45
D124046
LINK
bucket cylinder, right hand, inner, models with clam bucket, Includes: Ref. 46 and 47
1шт.
46
D31512
BUSHING,47.75mm ID x 57.15mm OD x 19.05mm L
link
1шт.
47
219-86
LUBE NIPPLE,1/8" NPTF
FITTING grease, straight, 1/8" pipe, self tapping
1шт.
48
REF
INSTRUCTION
POINTER right hand, inner link, models with clam bucket, See Figure 502
1шт.
49
D88417
CAGE ASSY.
CAGE nut, welded to right hand lift arm
2шт.
50
D78059
BRACKET
tube mounting, welded to lift arm
2шт.
Выбрано товаров: 53
