Запчасти Case 580E (646) - CAB HEADLINER AND WINDSHIELD WIPER COVERS, REAR WINDSHIELD WIPER MOTOR COVER (09) - CHASSIS/ATTACHMENTS

1

F45342

LINING

HEADLINER front, cab headliner and windshield wiper covers

1шт.

2

F45343

MOLDING

HEADLINER rear, cab headliner and windshield wiper covers

1шт.

3

L109555

GUARD

LOUVER headliner, cab headliner and windshield wiper covers

5шт.

4

F64519

SELF-TAP SCREW,Cross Wash Hd, #10-16 x 3/4"

SCREW special, cab headliner and windshield wiper covers

34шт.

4a

REF

INSTRUCTION

SEAL foam, rear headliner, 23-5/8" (600 mm) long, cut from A42905, see below, cab headliner and windshield wiper covers

1шт.

5

F45222

COVER

rear windshield wiper, front, used with Ref. 13, if used, two piece rear windshield wiper covers, if used

1шт.

6

F64519

SELF-TAP SCREW,Cross Wash Hd, #10-16 x 3/4"

SCREW special, two piece rear windshield wiper covers, if used

8шт.

7

F42837

BRACKET

cover mounting, straight, two piece rear windshield wiper covers, if used

2шт.

8

F41977

BRACKET

cover mounting, bent, two piece rear windshield wiper covers, if used

1шт.

9

F42836

BRACKET

wiper cover support, two piece rear windshield wiper covers, if used

1шт.

10

111-102

CARRIAGE BOLT,Short NK, 1/4"-20 x 5/8", G2

BOLT plated, 1/4" - 20 NC x 5/8", two piece rear windshield wiper covers, if used

3шт.

11

192-19

LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND

WASHER, LOCK, , 2 piece rear windshield wiper covers, if used 1/4"

3шт.

12

7770

NUT,Hex, 1/4 - 20, Cl 5

1/4"-20, G5, Two piece rear windshield wiper covers, if used

3шт.

13

F45221

MOLDING

COVER rear windshield wiper, used with Ref. 5, if used, two piece rear windshield wiper covers, if used

1шт.

14

131-861

SPRING NUT,Tinn, U, #10-24

Two piece rear windshield wiper covers, if used Tinn, U, #10-24

1шт.

15

F45306

COVER

rear windshield wiper motor, no longer used, Replace with Ref. 17, one piece rear windshield wiper covers, if used

1шт.

16

F64519

SELF-TAP SCREW,Cross Wash Hd, #10-16 x 3/4"

SCREW special, one used with Ref. 15 cover, two used with Ref. 17 cover, one piece rear windshield wiper covers, if used

1-2шт.

17

F45386

COVER ASSY

COVER rear windshield wiper motor, long, Replaces Ref. 15 cover used in production on some models, one piece rear windshield wiper covers, if used

1шт.

A42905

FOAM

SEAL foam, bulk roll, adhesive backed, 1/2" (13 mm) wide x 1/8" (3 mm) thick x 50 ft (15.2 m) long, one piece rear windshield wiper covers, if used

1шт.
