Артикул
Название
Примечание
Количество
1
D89795
BRACKET
brake pedal and master cylinder mounting before tractor PIN 9869266
1шт.
1a
D127611
BRACKET
brake pedal and master cylinder mounting on tractor 9869266 and after.
1шт.
1b
D67915
GROMMET
rubber, used with item 1A only
1шт.
2
113-207
BOLT,Hex, 3/8" - 16 x 1", Gr 5
2-4шт.
2a
113-2225
BOLT,Hex, 3/8" - 16 x 1-3/8", Gr 5
Upper mounting holes only on models with transaxle vent hose system, See Figure 294 Hex, 3/8"-16 x 1 3/8", G5
2шт.
3
192-21
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
4шт.
4
195-525
WASHER,3/8", SAE
flat, plated, 3/8"
4шт.
4a
195-525
WASHER,3/8", SAE
flat, plated, 3/8", upper left hand mounting hole only on models with transaxle vent hose system, See Figure 294
1шт.
4b
129-103
NUT,Hex, 3/8" - 16, Gr 5
NUT, , Upper LH mounting hole only on models with transaxle vent hose system, See Figure 294 3/8"-16, G5
1шт.
5
85-628
SET,Sq Hd, 3/8"-16 x 1 3/4"
SCREW set, square head, 3/8" - 16 NC x 1-3/4", cup point
1шт.
6
129-103
NUT,Hex, 3/8" - 16, Gr 5
NUT, 3/8"-16, G5
1шт.
7
D84355
SHAFT
pedal
1шт.
8
113-208
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
1шт.
9
195-525
WASHER,3/8", SAE
flat, plated, 3/8"
1шт.
10
131-52
NUT,3/8"-16, GC
NUT hex, self locking, plated, 3/8" - 16 NC
1шт.
11
195-2125
WASHER,1 5/16" x 2" x .109"
flat, pedal shaft, 1-1/4" bolt size, 1-5/16" ID x 2" OD x 1/8" thick
1шт.
12
D89845
SPACER
pedal, outer
2шт.
13
D94176
SPACER
pedal, center
1шт.
14
D90654
PEDAL
brake, right hand
1шт.
15
D90751
PEDAL
brake, left hand, includes pedal lock
1шт.
16
219-31
LUBE NIPPLE,30 Degree Elbow, 1/8" - 27 NPTF
FITTING grease, 30 degree, 1/8" NPT, special short
2шт.
17
REF
INSTRUCTION
CYLINDER master, brake, for correct assembly and components, See Figures 296 and 298
2шт.
18
113-208
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
4шт.
19
113-209
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
Lower Hex, 3/8"-16 x 1 1/2", G5
2шт.
20
195-525
WASHER,3/8", SAE
flat, plated, 3/8"
2шт.
21
D84475
BRACKET
brake lamp switches, if used
1шт.
22
192-21
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
6шт.
23
129-103
NUT,Hex, 3/8" - 16, Gr 5
NUT, 3/8"-16, G5
6шт.
24
D120218
ANCHOR
CLIP spring to master cylinder, if used
2шт.
25
D120911
SPRING
pedal return
2шт.
26
D94105
YOKE
CLEVIS master cylinder
2шт.
27
129-164
JAM NUT,Hex, 7/16" - 20, Gr 5
Jam, 7/16"- 20, G5
2шт.
28
141-64
CLEVIS PIN,7/16" x 1.190"
plated, special length 7/16" x 1.190"
2шт.
29
132-320
COTTER PIN,3/32" x 3/4"
PIN, SPLIT (COTTER), 3/32" x 3/4"
2шт.
30
D134622
SWITCH
brake lamp, if used
2шт.
31
182-530
SCREW,Sl Pan Hd, #6 - 32 x 1 1/4"
machine, pan head slotted, plated, No. 6 - 32 NC x 1-1/4"
4шт.
32
195-507
WASHER,#6
flat, plated, No. 6
4шт.
33
193-1003
NUT,Keps, w/LW,#6-32
AND LOCK WASHER plated, No. 6 - 32 NC
4шт.
