Запчасти Case 530CK (122) - SCREW TYPE LOCK, DRAFT-O-MATIC SENSING LINKAGE (35) - HYDRAULIC SYSTEMS

1

G48519

SPRING

- outer, sensing

1шт.

2

A35121

VALVE SPRING

SPRING - inner, sensing

1шт.

3

A30829

NUT

- spring adjusting

1шт.

4

25-148

JAM NUT,Jam, 1/2"-13, G5

- jam, 1/2" NC hex

1шт.

5

A38277

SUPPORT

EYE - centering, sensing spring (Replaces A35496)

1шт.

6

A35495

YOKE

ROD - adjusting spring

1шт.

7

141-6

CLEVIS PIN,1/2" x 1.360"

PIN - yoke

1шт.

8

132-48

COTTER PIN,1/8" x 1"

Pin, Split (Cotter), 1/8" x 1"

1шт.

9

A35795

ARM - sensing, L.H.

1шт.

10

413-632

BOLT,Hex, 3/8" - 16 x 2", Gr 5

- 3/8" x 2" N.C. hex. hd. (RH & LH)

2шт.

11

92-6

LOCK WASHER,3/8"

std. 3/8"

2шт.

12

25-106

NUT,3/8"-16, G5

- 3/8" N.C. hex.

2шт.

13

A36432

KEY - sensing, Serial Range: arm-shaft

2шт.

14

A35493

SHAFT

- pivot

1шт.

15

126-124

WOODRUFF KEY,#15, 1/4" x 1", HT

Mast to shaft #15, 1/4" x 1", HT

2шт.

16

A36889

BRACKET - pivot shaft

2шт.

17

A35117

BUSHING

2шт.

18

219-1

LUBE NIPPLE,1/8" - 27 NPTF

FITTING - 1/8" str.

2шт.

19

G4527

BRACKET - mast, adj. link (See ref. 1 Figure 123A)

1шт.

20

138-134

LOCK PIN,1/4" x 1", Slotted

PIN, 1/4" x 1", Slotted

2шт.

21

13-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd

Stop Hex, 3/8"-16 x 1 1/4", G5, Full Thd

1шт.

22

25-146

JAM NUT,Jam, 3/8"-16, G5

- jam, 3/8" N.C. hex.

1шт.

23

A35119

BOLT (SPREADER)

BOLT - lock-out (See ref. 3 Figure 123A)

1шт.

24

138-57

LOCK PIN,1/8" x 3/4", Slotted

PIN, 1/8" x 3/4", Slotted

1шт.

25

A35494

SPACER - L.H., pivot shaft (1-19/32")

1шт.

26

G49638

SPACER - R.H. pvt. shft (1-3/16" lg.)

1шт.

27

13-640

BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5

- pivot brkt. (3/8" x 2-1/2" N.C.)

8шт.

28

92-6

LOCK WASHER,3/8"

std. 3/8"

8шт.

29

G16735

PIN

- adjusting, Serial Range: link-mast

1шт.

30

A30338

PIN

KLINK PIN

1шт.

31

A35792

LINK

- (11-1/2") adjusting, frt. half (Course thrd.)

1шт.

31

G14068

LINK - (8") adjusting, frt. half (Coarse thrd.)

1шт.

32

A30379

TURNBUCKLE - (Coarse thrd.) Includes ref. 33

1шт.

33

219-14

LUBE NIPPLE,1/4" NPTF

FITTING - 1/4" str. drive

2шт.

34

G30583

LINK - adjusting, rear half (Coarse thrd.)

1шт.

35

25-1418

NUT,Jam, 1 1/8"-7, G5

- jam, 1-1/8" N.C. hex.

1шт.

36

A36228

UPPER LINK

TURNBUCKLE ASSY., Includes: Ref. 37 - 40

1шт.

37

NLS

NO LONGER SERVICED

LINK - adjusting, front half (Fine thrd.)

1шт.

38

A36223

TURNBUCKLE

- (Fine thrd.)

1шт.

39

A36226

LINK

- adjusting, rear half (Fine thrd.)

1шт.

40

25-1518

JAM NUT,Jam, 1 1/8"-12, G5

- jam, 1-1/8" N.F. hex.

1шт.

41

G16735

PIN

- mast, rear (Replaces A29700)

1шт.

42

A30338

PIN

KLINK PIN

1шт.

43

A30706

"S" HOOK -, Serial Range: chain-pin

1шт.

44

A30672

CHAIN - mast pin

2шт.

45

A29730

HOOK

"S" HOOK -, Serial Range: chain-link

1шт.

46

A35794

ARM - sensing, R.H.

1шт.

47

A35498

STOP - quadrant arm

1шт.

48

A35499

ARM - lower, quadrant

1шт.

49

A35112

BUSHING

- pivot

3шт.

50

G49413

WASHER

- wave, pivot bolt

3шт.

51

G49098

STEP BOLT

BOLT - pivot

3шт.

52

A35502

LINK - quadrant arm to lift arm

1шт.

63

A35491

BRACKET

- lift arm

1шт.

54

13-628

BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5

2шт.

55

A35123

QUADRANT

1шт.

113-204

BOLT,Hex, 3/8" - 16 x 1/2", Gr 5, Full Thd

2шт.

192-21

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

56

G15950

STOP

- quadrant

1шт.

57

G15951

NUT

- quadrant stop

2шт.

58

111-317

CARRIAGE BOLT,Short NK, 3/8"-16 x 1", G2

BOLT, CARRIAGE, Short NK, 3/8"-16 x 1", G2

2шт.
