Артикул
Название
Примечание
Количество
1
A35454
ARM - lift, rockshaft R.H.
1шт.
2
A35455
ARM - lift, rockshaft L.H.
1шт.
3
A35457
SCREW
BOLT - pivot, lift link to arm (R.H. thread)
2шт.
4
A37093
STEP BOLT,3/4" - 10 x 1 1/2" LH
BOLT - pivot, lift link to arm (L.H. thread)
2шт.
5
A35464
HANDLE
- adjusting screw
1шт.
7
A35465
KNOB
- adjusting handle
1шт.
8
25-146
JAM NUT,Jam, 3/8"-16, G5
- 3/8" N.C. hex. (Thin)
1шт.
9
64-632
SCREW
BOLT - 3/8" x 2" N.C. fill. hd.
1шт.
10
A35456
X
BLOCK - swivel, (w/R.H. thrd.) (Order A37093 & 1-A37092)
2шт.
11
A37092
BLOCK
- swivel (w/R.H. and L.H. thrd.)
2шт.
12
A35458
HOUSING - pivot, R.H. lift link
1шт.
13
219-1
LUBE NIPPLE,1/8" - 27 NPTF
FITTING - 1/8" str. (Lincoln #5000)
1шт.
14
A35459
PIN
- pivot, R.H. lift link
1шт.
15
A35463
SHAFT
- adjusting handle
1шт.
16
A35460
TUBE
- R.H. lift link
1шт.
17
NLS
NO LONGER SERVICED
- thrust, adjusting screw
1шт.
18
A35467
PLATE
- thrust, adjusting screw
1шт.
19
13-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd
4шт.
20
92-6
LOCK WASHER,3/8"
std. 3/8"
4шт.
21
A35469
SCREW,3/4" - 10 x 8 13/16"
- R.H. lift link
1шт.
22
A35470
YOKE
- lower, lift link
1шт.
23
138-136
LOCK PIN,1/4" x 1 1/4", Slotted
PIN, 1/4" x 1 1/4", Slotted
1шт.
24
A35475
PIN - pivot, L.H. lift link
1шт.
25
168-201
ROLL PIN - 1/2" x 1-1/4"
1шт.
26
A35474
YOKE - upper, L.H. lift link
1шт.
27
A35477
ROD - L.H. lift link
1шт.
28
A35470
YOKE
- lower, lift link
1шт.
29
138-136
LOCK PIN,1/4" x 1 1/4", Slotted
PIN, 1/4" x 1 1/4", Slotted
1шт.
30
A35471
PIN AND LOCK - yoke to draft arm (See A36883)
2шт.
30
A36883
PIN
& LOCK (w/heavy duty draft arm)
2шт.
31
A35472
PLATE
LOCK - float
2шт.
32
132-148
COTTER PIN,1/4" x 1 1/4"
Pin, Split (Cotter), 1/4" x 1 1/4"
2шт.
Выбрано товаров: 33
