Артикул
Название
Примечание
Количество
1
G11998
SPARE PART
COVER - valve
1шт.
3
G49400
WASHER
- cover nut
2шт.
2
25-106
NUT,3/8"-16, G5
- 3/8" N.C. hex.
2шт.
4
G46867
GROMMET
- rubber
2шт.
5
A36608
CAP
- breather
1шт.
6
G46866
GASKET
-, Serial Range: cover-head
1шт.
7
G2100
BRACKET
- front, rocket arm shaft
1шт.
8
13-656
BOLT,Hex, 3/8" - 16 x 3-1/2", Gr 5
- 3/8" x 3-1/2" N.C. hex. hd.
4шт.
9
A30058
WASHER
- bracket bolt
5шт.
10
A38181
SHAFT
- front, rocker arm (Replaces G11743)
1шт.
11
G2101
BRACKET
- center, rocker arm shaft
1шт.
12
G2102
BRACKET
- intermediate, rocker arm shaft
2шт.
13
A36615
BRACKET
- rear, rocker arm shaft
1шт.
14
G49067
BOLT
- drilled, rear bracket
1шт.
15
G45770
ARM
ROCKER ARM - R.H., Includes: Ref. 17
4шт.
16
G45771
ARM
ROCKER ARM - L.H., Includes: Ref. 17
4шт.
17
G49075
ADJUSTMENT SCREW,3/8" - 24 x 0.50"
- adjusting
1шт.
18
G48501
SPRING
- rocker arm shaft
4шт.
19
A38181
SHAFT
- rear, rocker arm (Replaces G11747)
1шт.
24
A36764
HEAD ASSY. - cylinder (Casting no. A36296), Includes: Ref. 25 - 33
14шт.
Order Ref. 24 P/N A36880 from Figure 40
1шт.
25
G49083
BOLT
- drilled, gear cover
1шт.
26
193-77
LOCK WASHER,Int Tooth, 1/2"
LOCKWASHER - 1/2" ET Shakeproof
1шт.
27
NSS
NOT SOLD SEPARAT
INSERT - valve seat (See ref. 55)
4шт.
28
A35175
STUD
- manifold clamp (3/8" x 2-7/16")
6шт.
29
A29431
STUD
- manifold & injector (3/8 x 1-3/4")
12шт.
30
A30036
PLUG
- expansion, 1-3/4" dia.
1шт.
31
G11724
LINER
- fuel injector
4шт.
32
NSS
NOT SOLD SEPARAT
GUIDE - intake valve (See ref. 57)
4шт.
33
NSS
NOT SOLD SEPARAT
GUIDE - exhaust valve (See ref. 56)
4шт.
34
G49065
SEAT
- valve spring
8шт.
35
A30025
SPRING
- valve
8шт.
36
NSS
NOT SOLD SEPARAT
RETAINER - valve spring (See ref. 59)
8шт.
37
G46851
SEAL
- rubber, valve stem
8шт.
38
NSS
NOT SOLD SEPARAT
LOCK - retainer, valve spring (See ref. 58)
16шт.
39
A35371
BOLT
- head to block (1/2" x 5")
11шт.
39
A35372
BOLT (SPREADER)
BOLT - head to block (1/2" x 5-1/2")
2шт.
41
A35370
BOLT
BOLT - head to block (1/2" x 3-1/4")
4шт.
42
A36903
STUD
- head & cover
2шт.
44
A37029
WASHER
- head bolt & stud (Replaces A29288)
19шт.
45
A36877
GASKET
-, Serial Range: head-block
1шт.
46
A36900
RING, PISTON
RING - fire, cylinder (Orange mark) (See ref. 47)
4шт.
47
A37031
RING
- fire (Oversize thickness black mark)
4шт.
48
NSS
NOT SOLD SEPARAT
VALVE - exhaust (See ref. 53)
4шт.
49
NSS
NOT SOLD SEPARAT
VALVE - intake (See ref. 54)
4шт.
50
G47079
ROD
- push
8шт.
51
G47077
TAPPET
- valve
8шт.
52
A39013
CAM
SHAFT - (See Figure 44) (Replaces A36853 & A38890)
1шт.
53
A41727
VALVE
S - exhaust (Set of 4) (Replaces G11948)
1шт.
54
A41726
VALVE
S - intake (Set of 4) (Replaces G11947)
1шт.
55
G11986
KIT
INSERTS - valve seat (Set of 4)
1шт.
56
G11946
GUIDE
S - exhaust valve stem (Set of 4)
1шт.
57
G11945
GUIDE
S - intake valve stem (Set of 4)
1шт.
58
G11929
LOCK
- valve spring retainer (Set of 4)
4шт.
59
G11927
RETAINER
S - valve spring (Set of 4 w/locks)
2шт.
Выбрано товаров: 55
