Запчасти Case 480E (3-14) - FUEL INJECTION NOZZLE, 4-390 ENGINE (03) - FUEL SYSTEM

A77553

KIT

KIT - injection nozzle, new, Includes: Ref. 1 - 12

4шт.

AR77553

REMAN-INJECT NOZZLE

Reman-Injection Nozzle Kit - injection nozzle, remanufactured, Includes: Ref. 1 - 12

4шт.

AC77553

INJECTOR ASSY.

Return Part Number

4шт.

JR919331

REMAN-FUEL INJECTOR

Remanufactured Injection Nozzle

4шт.

JC919331

CORE-FUEL INJECTOR

Return Part Number, injection

4шт.

1

J903380

SEAL

SEAL - connector

4шт.

2

J914472

NOZZLE INJECTION

NOZZLE ASSEMBLY - fuel injection, (New) (Order A77553 kit) (Replaces J909475 and J911340), Includes: Ref. 3 - 12

4шт.

2

JR914472

REMAN-INJECT NOZZLE

Reman-Injection Nozzle Assembly - injection, Remanufactured

4шт.

2

JC914472

CORE-INJECTION PUMP

Return Part Number injector (Use this number to return injector core for credit)

4шт.

3

J903927

O-RING,15.6 mm ID

O-RING - sealing

4шт.

4

J900808

SEAL

SEAL - injector

4шт.

Whenever a nozzle is removed from the cylinder head, J900808 gasket must be replaced before nozzle is installed in cylinder head.

1шт.

6

NSS

NOT SOLD SEPARAT

BODY ASSEMBLY - injector (Order A77553 kit)

1шт.

7

J905152

SPRING

SPRING - nozzle pressure

1шт.

8

J905153

SPINDLE

SEAT - nozzle pressure spring

1шт.

9

J905154

PLATE

STOP ASSEMBLY - nozzle valve

1шт.

10

NSS

NOT SOLD SEPARAT

TIP ASSEMBLY - nozzle injector (Order A77553 kit)

1шт.

11

A48201

NUT

NUT - cap, nozzle tip

1шт.

A48186

KIT

SHIM KIT - nozzle opening pressure, Includes: Ref. 12

1шт.

12

1806233C1

SHIM,1.00mm Thk

Nozzle (5 in kit)

1шт.

12

1806234C1

SHIM,1.04mm Thk

Nozzle (5 in kit)

1шт.

12

1806235C1

SHIM,1.08mm Thk

Nozzle (5 in kit)

1шт.

12

1806236C1

SHIM,1.10mm Thk

Nozzle (5 in kit)

1шт.

12

1806237C1

SHIM,1.14mm Thk

Nozzle (5 in kit)

1шт.

12

1806238C1

SHIM,1.18mm Thk

Nozzle (5 in kit)

1шт.

12

1806239C1

SHIM,1.20mm Thk

Nozzle (5 in kit)

1шт.

12

1806240C1

SHIM,1.24mm Thk

Nozzle (5 in kit)

1шт.

12

1806241C1

SHIM,1.28mm Thk

Nozzle (5 in kit)

1шт.

12

1806242C1

SHIM,1.30mm Thk

Nozzle (5 in kit)

1шт.

12

1806243C1

SHIM,1.34mm Thk

Nozzle (5 in kit)

1шт.

12

1806244C1

SHIM,1.38mm Thk

Nozzle (5 in kit)

1шт.

12

1806245C1

SHIM,1.40mm Thk

Nozzle (5 in kit)

1шт.

12

1806246C1

SHIM,1.44mm Thk

Nozzle (5 in kit)

1шт.

12

1806247C1

SHIM,1.48mm Thk

Nozzle (5 in kit)

1шт.

12

1806248C1

SHIM,1.50mm Thk

Nozzle (5 in kit)

1шт.

12

1806249C1

SHIM,1.54mm Thk

Nozzle (5 in kit)

1шт.

12

1806250C1

SHIM,1.58mm Thk

Nozzle (5 in kit)

1шт.

12

1806251C1

SHIM,1.60mm Thk

Nozzle (5 in kit)

1шт.

12

1806252C1

SHIM,1.64mm Thk

Nozzle (5 in kit)

1шт.

12

1806253C1

SHIM,1.68mm Thk

Nozzle (5 in kit)

1шт.

12

1806254C1

SHIM,1.70mm Thk

Nozzle (5 in kit)

1шт.

12

1806255C1

SHIM,1.74mm Thk

Nozzle (5 in kit)

1шт.

12

1806256C1

SHIM,1.78mm Thk

Nozzle (5 in kit)

1шт.

12

1806257C1

SHIM,1.80mm Thk

Nozzle (5 in kit)

1шт.

12

1806258C1

SHIM,1.84mm Thk

Nozzle (5 in kit)

1шт.

12

1806259C1

SHIM,1.88mm Thk

Nozzle (5 in kit)

1шт.

12

1806260C1

SHIM,1.90mm Thk

Nozzle (5 in kit)

1шт.

12

1806261C1

SHIM,1.94mm Thk

Nozzle (5 in kit)

1шт.

12

1806262C1

SHIM,1.98mm Thk

Nozzle (5 in kit)

1шт.
