Запчасти Case 36 (58) - CYLINDER IDENTIFICATION, SWING CYLINDERS

1

D45303

CYLINDER

- hydraulic, L.H. swing (4-1/2" I.D. x 11-3/8" stroke) Parts list figure 66

1шт.

1

D45304

CYLINDER

- hydraulic, R.H. swing (4-1/2" I.D. x 11-3/8" stroke) Parts list figure 66

1шт.

2

G32675

CYLINDER - hydraulic, L.H. swing (4-1/2" I.D. x 11-3/8" stroke) Parts list figure 64

1шт.

2

G32676

CYLINDER - hydraulic, R.H. swing (4-1/2" I.D. x 11-3/8" stroke) Parts list figure 64

1шт.

2

G32878

CYLINDER

- hydraulic, L.H. swing (4-1/2" I.D. x 11-3/8" stroke) Parts list figure 62

1шт.

2

G32879

CYLINDER

- hydraulic, R.H. swing (4-1/2" I.D. x 11-3/8" stroke) Parts list figure 62

1шт.

3

G33628

CYLINDER

- hydraulic, R.H. swing (4-1/2" I.D. x 11-3/8" stroke) Parts list figure 60

1шт.

3

G33628

CYLINDER

- hydraulic, R.H. swing (4-1/2" I.D. x 11-3/8" stroke) Parts list figure 60

1шт.

3

G33629

CYLINDER BLOCK

CYLINDER - hydraulic, L.H. swing (4-1/2" I.D. x 11-3/8" stroke) Parts list figure 60

1шт.

1

D42708

CYLINDER - hydraulic, stabilizer (4" I.D. x 21-3/8" stroke) Parts list figure 74

2шт.

2

G32601

CYLINDER - hydraulic, stabilizer (4" I.D. x 21-3/8" stroke) Parts list figure 72

2шт.

3

G33828

CYLINDER

- hydraulic, stabilizer (4" I.D. x 21-3/8" stroke) Parts list figure 70

2шт.

2

D45313

WASHER

CYLINDER - hydraulic, boom (5" I.D. x 39-3/16" stroke) Parts list figure 78

1шт.

2

G32692

CYLINDER

- hydraulic, boom (5" I.D. x 39-3/16" stroke) Parts list figure 76

1шт.

1

D44658

CYLINDER - hydraulic, crowd (4-1/2" I.D. x 40-1/8" stroke) Parts list figure 84

1шт.

2

D49525

CYLINDER BLOCK

CYLINDER - hydraulic, crowd (4-1/2" I.D. x 4-1/8" stroke) Parts list figure 84

1шт.

2

G32683

HYD TUBE,4.5" ID x 52.62" L

CYLINDER - hydraulic, crowd (4-1/2" I.D. x 4-1/8" stroke) Parts list figure 82

1шт.

2

G33810

CYLINDER BLOCK

CYLINDER - hydraulic, crowd (4-1/2" I.D. x 40-1/8" stroke) Parts list figure 82

1шт.

2

G34255

CYLINDER - hydraulic, crowd (4-1/2" I.D. x 40-1/8" stroke) Parts list figure 80

1шт.

2

G34323

CYLINDER - hydraulic, crowd (4-1/2" I.D. x 40-1/8" stroke) Parts list figure 80

1шт.

1

D42628

CYLINDER

- hydraulic, bucket (4" I.D. x 27-1/4" stroke) Parts list figure 88

1шт.

2

D49524

CYLINDER - hydraulic, bucket (4" I.D. x 27-1/4" stroke) Parts list figure 88

1шт.

2

G32687

CYLINDER

- hydraulic, bucket (4" I.D. x 27-1/4" stroke) Parts list figure 86

1шт.

2

G33834

CYLINDER

- hydraulic, bucket (4" I.D. x 27-1/4" stroke) Parts list figure 86

1шт.
