Запчасти Case 35WL (92) - DECALS

Схема запчастей Case 35WL - (92) - DECALS

Артикул

Название

Примечание

Количество

1

321-5506

DECAL

- "CASE", with tread, if used

1шт.

2

321-5129

DECAL

- "CASE", with tread, right-hand, standard backhoe dipper, if used, W14 only

1шт.

3

321-5130

DECAL

- "CASE", with tread, left-hand, standard backhoe dipper, if used, W14 only

1шт.

4

321-5569

DECAL

- operator's instructions, control levers

1шт.

5

321-3056

DECAL

- caution, transport

1шт.

6

321-4481

DECAL

- warning, swing

2шт.

7

321-3058

DECAL

- important, swing

1шт.

8

321-3139

DECAL

- "Extendahoe"

2шт.

9

321-5572

DECAL

- operators instructions, extendahoe

1шт.

10

321-6046

WARNING DECAL

DECAL, WARNING, Lifting objects

1шт.

11

D87870

DECAL

REFLECTOR - red, rear

2шт.

12

321-5568

DECAL

- operators information, swing pedals

1шт.

13

321-5573

DECAL

- control, swing, extendable dipper, if used

1шт.

14

D55216

PAD,2" x 9"

STRIP - anti-skid, W14 only

4шт.

15

D52564

SPRING

- SMV emblem retaining

1шт.

16

195-518

WASHER,1/4", SAE

- flat, 1/4", plated, SMV emblem

2шт.

17

129-409

WING NUT,1/4"-20

NUT, WING, , SMV Emblem 1/4"-20

2шт.

18

D52581

TRAFFIC SIGN

EMBLEM - plate and decal, SMV

1шт.

19

321-1751

DECAL

- emblem, SMV

1шт.

20

113-3

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5

Used when storing emblem only, not shown, SMV Hex, 1/4"-20 x 3/4", G5, Full Thd

2шт.

21

7770

NUT,Hex, 1/4 - 20, Cl 5

1/4"-20, G5, Used when storing emblem only, not shown, SMV

2шт.

Выбрано товаров: 21
