Запчасти Case 35C (9-60) - DECALS (09) - CHASSIS/ATTACHMENTS

Схема запчастей Case 35C - (9-60) - DECALS (09) - CHASSIS/ATTACHMENTS

Артикул

Название

Примечание

Количество

1

D123951

DECAL

- Case, brown, 9 right-hand treadmarks (remove the last 3 treadmarks to fit), used on W14 Loader models and 855E Crawlwer models

1шт.

1a

D123959

DECAL

- Case, tan, 9 right-hand treadmarks, used on 850C and 850D/855D Crawler models only, not shown

1шт.

2

D123977

DECAL

- standard backhoe control pattern, upper

1шт.

3

321-3056

DECAL

- Caution, operate backhoe from seat position only

1шт.

4

321-4481

DECAL

- Warning, keep clear of this area swinging boom can crush

2шт.

5

321-3058

DECAL

- Important, due to possible interference with stabilizer or tractor

1шт.

6

D123945

DECAL

- extendahoe

2шт.

7

D123941

DECAL

- extendahoe control pattern, upper

1шт.

8

321-6046

WARNING DECAL

DECAL, WARNING, If you use the backhoe to lift a load that is too heavy

1шт.

9

D87870

DECAL

REFLECTOR - red, rear

2шт.

10

D123976

DECAL

- backhoe control pattern, lower

1шт.

11

D123940

DECAL

- extendahoe control pattern, lower

1шт.

11a

L111854

DECAL

- Case, brown, 4 right-hand treadmarks, right-hand side of dipper housing, W14 Loader models only

1шт.

11b

L111855

DECAL

- Case, brown, 4 left-hand treadmarks, left-hand side of dipper housing, W14 Loader models only, not shown

1шт.

12

D52564

SPRING

- emblem retaining, SMV

1шт.

13

495-11028

WASHER,1/4", SAE

(flat, 9/32 x 5/8 x 1/16"), SMV EMBLEM 1/4", SAE

2шт.

14

129-409

WING NUT,1/4"-20

NUT, WING, , SMV Emblem 1/4"-20

2шт.

15

D52581

TRAFFIC SIGN

EMBLEM - plate and decal, SMV EMBLEM

1шт.

16

321-4311

DECAL

- SMV emblem

1шт.

17

413-412

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5

- hex, 1/4 NC x 3/4 inch, Used when storing emblem only, Not shown, SMV

2шт.

18

425-104

NUT,1/4"-20, Cl 5

- hex, 1/4 inch NC, used when storing emblem only, not shown, SMV

2шт.
