Запчасти Case 33S (238) - DECALS (EARLY PRODUCTION)

Схема запчастей Case 33S - (238) - DECALS (EARLY PRODUCTION)

Артикул

Название

Примечание

Количество

1

321-921

DECAL

- backhoe, control complete (Individual levers)

1шт.

2

321-917

DECAL

- backhoe control, dipper arm and bucket (Twin lever)

1шт.

3

321-918

DECAL

- backhoe control, boom and swing (Twin lever)

1шт.

4

321-919

DECAL

- backhoe control, stabilizer (Twin lever)

1шт.

5

321-695

DECAL

- check oil level, on R.H. loader frame

1шт.

6

321-663

DECAL

- patent, L.H. loader frame

1шт.

7

321-230

DECAL

- diesel fuel, on fuel tank

1шт.

321-18

DECAL

- gasoline (Not shown) On fuel tank

1шт.

8

321-995

DECAL

- 580, on each side of hood

2шт.

9

321-996

DECAL

- Case, R.H. hood

1шт.

321-997

DECAL

- Case, L.H. (Not shown)

1шт.

10

321-122

DECAL

- warning, pressure cap (On radiator)

1шт.

11

321-1030

DECAL

- shifting (Dual range) L.H. side of dash

1шт.

12

321-946

DECAL

- shifting (4 speed) L.H. side of dash

1шт.

13

321-667

DECAL

- starting, diesel models (R.H. side of dash)

1шт.

14

321-666

DECAL

- starting, gas models (R.H. side of dash)

1шт.

15

321-662

DECAL

- warning, lower or block hydraulically (At loader controls)

1шт.

16

321-229

DECAL

- hydraulic fluid, on R.H. loader frame

1шт.

17

321-920

DECAL

- loader control valve, on loader controls

1шт.

18

321-1003

DECAL

- CK, on loader lift frame and backhoe dipper

4шт.

19

321-1010

DECAL

- Case, on loader lift frame and backhoe boom

4шт.

20

321-1234

DECAL

- warning, do not roll back bucket (At loader controls) Only on models without anti-rollback

1шт.

Выбрано товаров: 22
