Запчасти Case 580B (149A) - DIFFERENTIAL LOCK (06) - POWER TRAIN

1

D50691

PLATE

- floor, L.H. rear

1шт.

2

353-473

BUSHING

GROMMET - floor plate

1шт.

3

D51637

ROD

PEDAL - differential lock

1шт.

4

D54487

SUPPORT

- floor plate

1шт.

5

13-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd

4шт.

6

D51635

BRACKET - support, linkage

2шт.

7

92-6

LOCK WASHER,3/8"

med. sect. 3/8"

4шт.

8

25-106

NUT,3/8"-16, G5

- hex. (3/8" - 16 N.C.)

4шт.

9

141-4

CLEVIS PIN,3/8" x 1.060"

PIN, CLEVIS, 3/8" x 1.060"

3шт.

10

132-26

COTTER PIN

Pin, Split (Cotter), 3/32" x 3/4"

3шт.

11

213-4

ADJUSTABLE CLEVIS,3/8"-24 x 2 1/2"

YOKE - rod end

3шт.

12

25-116

NUT,Hex, 3/8"-24, G5

- hex. (3/8" - 24 N.F.)

3шт.

13

D51641

ROD - cross, linkage

1шт.

14

95-6

WASHER,3/8"

- plain () 3/8"

2шт.

15

132-26

COTTER PIN

Pin, Split (Cotter), 3/32" x 3/4"

2шт.

16

D51637

ROD

- connecting, differential lock

1шт.
