Запчасти Case 580B (128) - SOLENOID (04) - ELECTRICAL SYSTEMS

G44891

SOLENOID

ASSY. - (Delco-Remy #1114356) (See Delco-Remy dealer for all parts illustrated but not listed), Inlcudes: Ref. 1 - 8

1шт.

1

A42061

SWITCH

CONTACT ASSY.

1шт.

2

A42059

SPRING

contact return

1шт.

3

A42060

HALF BLADE

contact

1шт.

4

129-16

NUT,#8-32

NUT, #8-32

4шт.

5

87016560

JAM NUT,Jam, 3/8"-16, G5

NUT, Jam, 3/8"-16, G5

3шт.

6

192-16

LOCK WASHER,Helical Spring, #8, 0.17" ID, CST, ZND

Washer, Lock, #8

2шт.

7

192-21

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

1шт.

8

A40221

SPRING

plunger return

1шт.

A42398

CONVERSION KIT

CONVERSION KIT - (To convert A36582 & A36583 starters into an A39839 starter), Inlcudes: Ref. 16 - 22

1шт.

16

A25547

ARMATURE

A42398 starter conversion kit

1шт.

17

A25548

COIL

field, A42398 starter conversion kit

1шт.

18

R15030

ELECTRICAL WIRE

WIRE LEAD - ground, brush (#10 wire, 2" long), A42398 starter conversion kit

2шт.

19

173-212

SCREW,Sl Rnd Hd, #10 - 24 x 1/2"

#10-24 x 1/2" rd. hd., A42398 starter conversion kit

4шт.

20

192-18

LOCK WASHER,Helical Spring, #10, 0.196" ID, CST, ZND

WASHER, LOCK, , A42398 starter conversion kit #10

4шт.

21

129-17

NUT,Hex, #10 - 24

hex., A42398 starter conversion kit #10-24

4шт.

22

321-2936

DECAL

converted motor, A42398 starter conversion kit

1шт.

A43662

CONVERSION KIT

CONVERSION KIT - (To convert A38413 starter into A39839 starter), Inlcudes: Ref. 25 - 29

1шт.

87421540

REMAN-STARTER DRIVE

580B CASE CONSTRUCTION KING TRACTOR W/SHUTTLE TRANSMISSION, Reman for New PN A43662

1шт.

87421541

CORE-STARTER DRIVE

Return Part Number

1шт.

25

A43652

DRIVE

starter (10 tooth pinion), A43662 starter conversion kit

1шт.

25

87421540

REMAN-STARTER DRIVE

580B CASE CONSTRUCTION KING TRACTOR W/SHUTTLE TRANSMISSION, Reman for New PN A43652

1шт.

25

87421541

CORE-STARTER DRIVE

Return Part Number

1шт.

26

A43653

HOUSING

FRAME ASSY. - starter drive end, A43662 starter conversion kit, Inlcudes: Ref. 27 and 28

1шт.

27

A40227

BUSHING

(1/2 x 9/16 x 25/32"), A43662 starter conversion kit

1шт.

28

R15041

SPARE PART locating, A43662 starter conversion kit

1шт.

29

321-2937

DECAL

converted motor, A43662 starter conversion kit

1шт.

A44799

KIT

CONVERSION KIT - (To convert A36582 starter into A51873 starter), Inlcudes: Ref. 35 - 38

1шт.

87421540

REMAN-STARTER DRIVE

580B CASE CONSTRUCTION KING TRACTOR W/SHUTTLE TRANSMISSION, Reman for New PN A44799

1шт.

87421541

CORE-STARTER DRIVE

Return Part Number

1шт.

35

A43652

DRIVE

starter, A44799 starter conversion kit

1шт.

36

A44495

LUG

FRAME ASSY. - starter drive end, A44799 starter conversion kit, Inlcudes: Ref. 37

1шт.

37

A25387

BEARING

15/32 x 5/8 x 13/16", A44799 starter conversion kit

1шт.

38

321-3016

DECAL

converted motor (Replaces 321-2748), A44799 starter conversion kit

1шт.
