Запчасти Case 580B (237C) - SWINGING DRAWBAR, ASSIST HANDLE AND STEP, SWINGING DRAWBAR, ASSIST HANDLE & STEP (09) - CHASSIS/ATTACHMENTS

1

A37809

BAR

DRAWBAR - swinging, tractor

1шт.

2

13-1024

BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 5, Full Thd

4шт.

3

92-10

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

4шт.

4

G30266

SUPPORT

- rear, drawbar

1шт.

5

G10617

SUPPORT

- front, drawbar

1шт.

6

13-1224

BOLT,Hex, 3/4" - 10 x 1-1/2", Gr 5

2шт.

7

92-12

LOCK WASHER,3/4"

WASHER, LOCK, 3/4"

2шт.

8

G14403

PIN

& LATCH - drawbar mounting

1шт.

9

A35270

WASHER

- spring type

1шт.

10

113-206

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

Assist handle and step Hex, 3/8"-16 x 3/4", G5, Full Thd

4шт.

11

192-21

LOCK WASHER,3/8"

WASHER, LOCK, , Assist handle and step 3/8"

4шт.

12

195-525

WASHER,3/8", SAE

assist handle and step 3/8", SAE

4шт.

13

25-106

NUT,3/8"-16, G5

- hex. (3/8"-16 N.C.), assist handle and step

1шт.

14

D55308

HANDLE - operator assist, assist handle and step

1шт.

15

D55139

PLATE - cover, L.H. (Drawbar models only), assist handle and step

1шт.

16

D55140

PLATE - cover, R.H. (Drawbar models only), assist handle and step

1шт.

17

D55504

WRAPPER - instrument panel, assist handle and step

1шт.

18

13-1016

BOLT,Hex, 5/8" - 11 x 1", Gr 5, Full Thd

Assist handle and step Hex, 5/8"-11 x 1", G5, Full Thd

1шт.

19

92-10

LOCK WASHER,5/8"

WASHER, LOCK, , Assist handle and step 5/8"

1шт.

20

95-10

WASHER,5/8"

- plain (), assist handle and step 5/8"

1шт.

21

D55309

STEP - access, operator, assist handle and step

1шт.

22

13-624

BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5

HHCS - (3/8"-16 N.C. x 1-1/2"), assist handle and step

1шт.

23

92-6

LOCK WASHER,3/8"

WASHER - lock, , assist handle and step 3/8"

1шт.

24

95-6

WASHER,3/8"

- plain (), assist handle and step 3/8"

1шт.
