Запчасти Case 35 (464) - TRACTOR NOISE CONTROL COMPONENTS, USED ON UNITS WITH CAB

1

REF

INSTRUCTION

PAD - hood, top, see Figure 470, Ref. 3, for dimensional information

1шт.

1a

REF

INSTRUCTION

PAD - hood, side, front, see Figure 470, Ref. 1, for dimensional information

2шт.

2

REF

INSTRUCTION

PAD - hood, side, rear, see Figure 470, Ref. 2, for dimensional information

2шт.

3

113-102

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

Hex, 5/16"-18 x 3/4", G5, Full Thd

2шт.

4

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

WASHER, LOCK, 5/16"

2шт.

5

195-521

WASHER,5/16", SAE

- plain, 5/16"

2шт.

6

9635082

NUT,5/16" - 18, Gr 5

2шт.

7

D56011

PANEL - noise deflection, LH, Includes: Ref. 7A

1шт.

7a

REF

INSTRUCTION

PAD - noise deflection, LH, see Figure 470, Ref. 6, for dimensional information

1шт.

8

D56010

PANEL - noise deflection, RH, Includes: Ref. 8A

1шт.

8a

REF

INSTRUCTION

PAD - noise deflection, RH, see Figure 470, Ref. 6, for dimensional information

1шт.

9

D55532

MUFFLER

- exhaust, noise reduction

1шт.

10

D53101

PIPE

EXTENSION - exhaust

1шт.

11

G45410

CLAMP

-, Serial Range: extension-muffler

1шт.

12

D55187

PLATE - baffle

1шт.

12a

REF

INSTRUCTION

PAD - baffle, see Figure 422, Ref. 10, for dimensional information

1шт.

13

D55504

WRAPPER - instrument panel

1шт.

13a

REF

INSTRUCTION

PAD - wrapper, side, see Figure 470, Ref. 9, for dimensional information

2шт.

13b

REF

INSTRUCTION

PAD - wrapper, top, see Figure 470, Ref. 5, for dimensional information

1шт.

14

D61562

MAT - floor, operator's compartment

1шт.

15

D55023

PLATE ASSY.

PLATE - floor, front, RH

1шт.

15a

REF

INSTRUCTION

PAD - front floor, see Figure 470, Ref. 12, for dimensional information

2шт.

16

D55022

PLATE

- floor, front, LH

1шт.

17

D56433

PLATE ASSY.

PLATE - floor, rear, RH

1шт.

18

D55462

PLATE ASSY.

PLATE - floor, rear, LH

1шт.

18a

REF

INSTRUCTION

PAD - rear floor, see Figure 470, Ref. 13, for dimensional information

2шт.

19

D55028

PLATE

- battery access cover

1шт.

19a

REF

INSTRUCTION

PAD - battery access cover, see Figure 470, Ref. 17, for dimensional information

1шт.

20

REF

INSTRUCTION

TRIM - quickedge, cut from D33500 bulk

1шт.

21

REF

INSTRUCTION

TRIM - quickedge, cut from D33500 bulk

1шт.

D33500

LINING

TRIM - quickedge bulk, cut from D52812

1шт.

22

D59546

MAT - floor, backhoe control tower

1шт.
