Запчасти Case 35 (432) - SIDE SHIFT BACKHOE, SWING TOWER AND BOOM LOCK, EARLY PRODUCTION

1

E19488

LATHE

TOWER - swing

1шт.

2

D59234

TOWER - swing, used on models sold in Japan only, Includes: Ref. 3 and 4

1шт.

3

D49429

BUSHING

- pivot, boom cylinder

2шт.

4

D50132

SPACER,57.15mm ID x 114.3mm OD x 7.94mm L

- mounting frame to swing tower

1шт.

5

RESERVED

1шт.

6

195-2155

WASHER,2 1/16" x 3" x .109"

- plain, 2" ID

2шт.

E19477

CABLE

ASSEMBLY - control, boom lock, Includes: Ref. 7 - 14

1шт.

7

129-528

NUT

- hex, lock, 3/8" - 24 NF

2шт.

8

195-525

WASHER,3/8", SAE

- plain, 3/8"

2шт.

9

NSS

NOT SOLD SEPARAT

CABLE - control

1шт.

10

E30260

NUT

- hex, 5/8" - 18 NF

1шт.

11

193-63

LOCK WASHER,Int Tooth, 5/8"

WASHER - lock, internal shakeproof, 5/8"

1шт.

12

NUT - special, cable retainer

1шт.

13

L32679

HANDLE

- control, lock

1шт.

14

E30262

SCREW

- special, handle retainer

1шт.

15

D49879

PIN

- locking, swing tower

1шт.

16

D33805

PIN

- Klik

1шт.

17

E19641

SLEEVE CYLINDER

SLEEVE - cable protector

1шт.

18

L32208

CLAMP

COLLAR -, Serial Range: cable-latch

1шт.

19

135-359

GROOVED PIN,1/4" x 1 1/2", Type F

PIN - roll, groove type, 1/4" dia x 1-1/2"

2шт.

20

E19470

AXLE PIN

PIN - latch pivot

2шт.

21

E19461

LEVER

LATCH - boom lock

1шт.

22

D63988

SPRING

- return, latch

1шт.

23

13-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd

Latch stop Hex, 3/8"-16 x 1 1/4", G5, Full Thd

1шт.

24

25-106

NUT,3/8"-16, G5

- hex, 3/8" - 16 NC

1шт.

25

D49863

PIN,44.45mm OD x 248.92mm L

- swing, Serial Range: cylinder-tower

2шт.

26

13-820

BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5, Full Thd

2шт.

27

92-8

LOCK WASHER,1/2"

2шт.

28

95-8

WASHER,1/2"

- plain 1/2"

2шт.

29

E18157

PLATE

- pin retainer

2шт.

30

D50170

PIN

- pivot, swing tower

2шт.

31

2191

FUEL FILTER

GREASE FITTING - straight, 1/8" NPT

2шт.

32

D26919

SNAP RING,#200, Ext

Ring, Snap, , pin #200, Ext

2шт.

33

R10830

WASHER

- spacer

1шт.

34

13-648

BOLT,Hex, 3/8" - 16 x 3", Gr 5

- hex, 3/8" - 16 NC x 3"

2шт.

35

E18390

CLAMP

- hose, front

1шт.

36

E18391

CLAMP

- hose, rear

1шт.

37

92-6

LOCK WASHER,3/8"

2шт.

38

25-106

NUT,3/8"-16, G5

- hex, 3/8" - 16 NC

2шт.
