Запчасти Case 35 (036) - BACKHOE INTERMEDIATE HYDS, COMMERCIAL - CROSS VALVES USED ON MDLS W/ BACKHOE SN BEF 5219901

1

D52800

COUPLING, QUICK, FEM

COUPLING - quick disconnect, female half, parts list Figure 162

1шт.

2

217-1020

90 ELBOW,3/4" - 14 Female x 3/4" - 14 Male

Street 90º, 3/4"-14 Female x 3/4"-14 Male

1шт.

3

D52667

HOSE

- pressure line to stabilizer valve, 36" (914 mm) long

1шт.

4

218-5124

ELBOW,90 Degree Elbow, 1-5/16" - 12 Male JIC x 1-1/16" - 12 Male ORB

Adjustable, Includes Ref. 5 90º, 1 5/16"-12, 37º x 1 1/16"-12, O-Ring

1шт.

5

218-5008

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

12-1, 90 Duro, .924 ID x .116" Thk

1шт.

6

D50420

VALVE

ASSEMBLY - stablizer control, see Figure 66 for related parts and Figure 210 for component parts

1шт.

7

218-5064

HYD CONNECTOR,1-1/16" - 12 Male JIC x 1-1/16" - 12 Male ORB

CONNECTOR - male, staright, Incl. Ref. 8

1шт.

8

218-5008

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

12-1, 90 Duro, .924 ID x .116" Thk

1шт.

9

D50554

HOSE

- stablizer control valve to backhoe control valve 22" (599 mm) long

1шт.

10

218-5077

HYD CONNECTOR,1-1/16" - 12 Male JIC x 1-5/16" - 12 Male ORB

CONNECTOR - male, straight, Incl. Ref. 11

1шт.

11

218-5010

O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro

1шт.

12

D50560

LOCK VALVE

VALVE - backhoe control, see Figure 76 for related parts and Figure 180 for component parts

1шт.

13

218-5110

ELBOW,90 Degree Elbow, 1-5/16" - 12 Male JIC x 1-5/16" - 12 Male ORB

90º, adjustable, Incl. Ref. 14

1шт.

14

218-5010

O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro

1шт.

15

D50390

HOSE

- return, backhoe control valve to tee, 19-1/2" (496 mm) long

1шт.

16

D50390

HOSE

- return, backhoe control valve to tee, 19-1/2" (496 mm) long

1шт.

17

D52669

TUBE

ASSEMBLY - stablizer valve return

1шт.

18

222-3024

CONNECTOR, ELEC,1 1/8"-12 x 1 1/16"-12

CONNECTOR ASSEMBLY - tube stabilizer valve return parts list Figure 148

1шт.

19

218-1250

BHD LOCK NUT,Blkhd, 1 5/16"-12

NUT, LOCK, Blkhd, 1 5/16"-12, Coupling

1шт.

20

D52673

COUPLING, BREAK AWAY

COUPLING - quick disconnect, male half parts list Figure 162

1шт.
