1
D48723
HITCH ASSEMBLY - complete, Includes: Ref. 2
1шт.
2
D48700
CHAIN - safety
2шт.
3
321-1021
DECAL
- Case, hitch frame (If used)
2шт.
3a
321-1438
DECAL
- Case, hitch frame (If used)
2шт.
4
321-1406
DECAL - patent, hitch frame
1шт.
5
321-1409
DECAL - towing speed
1шт.
6
D50767
BRACKET - bucket retaining
1шт.
7
13-1032
BOLT,Hex, 5/8" - 11 x 2", Gr 5
2шт.
8
D48699
CHAIN - tractor axle to loader arm
2шт.
9
D48726
AXLE AND FENDER ASSEMBLY (Includes wheel hubs and brakes) Parts list Figure 198
1шт.
10
321-1010
DECAL
- Case, rear of axle (If used)
1шт.
10a
321-1440
DECAL
- Case, rear of axle (If used)
1шт.
11
D48709
PIN - axle to backhoe frame
2шт.
12
D33805
PIN
- klik, D48709 pin retaining
4шт.
13
D48725
BRACKET - attaches to backhoe frame
2шт.
14
D52016
PLATE - attaches to loader bucket
2шт.
