Артикул
Название
Примечание
Количество
1
47575069
FUEL TANK
31 Gallon
1шт.
See Fig 10.216.AI (01) For Service Parts
1шт.
2
47541051
FUEL FILTER,W/ WIF Sensor
Tier 4B
1шт.
4
627-20060
BOLT,Hex, M20 x 2.5 x 60mm, Cl 10.9, Full Thd
4шт.
5
302358A1
WASHER,21mm ID x 54mm OD x 4mm Th
Heat Treated
2шт.
6
185926A1
SPACER,21mm x 40mm x 6.6mm Th
Tank
2шт.
7
87360280
SPACER,22mm ID x 57mm OD x 8.25 Th
Tank
1шт.
8
L11541
CABLE TIE,203.2mm L, Nylon
2шт.
9
84391629
RIGID TUBE
Fuel Line, Suction, Filter to Engine
1шт.
10
47432274
PLATE
Fuel Filter Mounting
1шт.
11
895-15008
WASHER,9mm ID x 20mm OD x 1.6mm Thk
2шт.
12
614-8025
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd
2шт.
13
614-12020
BOLT,Hex, M12 x 1.75 x 20mm, Cl 8.8, Full Thd
2шт.
14
84425860
FITTING,90 Degree, for Fuel Hose 9.5mm ID
Fuel,
1шт.
15
214-1704
HOSE CLAMP,#04, 0.25" - 0.62", Type M Worm
2шт.
16
214-1706
HOSE CLAMP,#06, 0.44" - 0.78", Type M Worm
4шт.
17
217-117
FITTING,1/4" Hose x 1/4" NPTF, Fem, Barbed
1шт.
18
86010402
CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, P Type
1шт.
19
87417721
THREADED INSERT,M10 x 1.5-6H x 29 L
1шт.
20
130047A1
BREATHER ASSY.
Vent, Fuel
1шт.
22
614-10035
BOLT,Hex, M10 x 1.5 x 35mm, Cl 8.8, Full Thd
1шт.
23
87656146
FUEL HOSE,6.35 mm ID x 880.00 mm
1шт.
24
84420127
FUEL HOSE
Fuel Hose, Inlet
1шт.
25
47592385
HOSE
Fuel Hose, Outlet
1шт.
26
191704A1
HOSE PROTECTION,19mm ID x 25mm OD x 460mm L
1шт.
27
47589468
HOSE PROTECTION,34mm ID x 750mm L
Guard
1шт.
28
L18331
CABLE TIE,375.9mm L, Nylon, Black
4шт.
Выбрано товаров: 29
