Запчасти Case 588H (10.408.03[01]) - OIL COOLER INSTALLATION, HARDWARE AND LINES (10) - ENGINE

1

87715487

RADIATOR HOSE,7.90 mm ID x 440.00 mm, SAE J30, SAE 30R6 Or SAE 20 R4 Class D1

1шт.

2

614-8025

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd

6шт.

3

87655042

SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk

M8

10шт.

4

214-1704

HOSE CLAMP,#04, 0.25" - 0.62", Type M Worm

2шт.

5

87301325

FITTING,5/16" Hose X 1/4" NPTF Beaded

Stem

1шт.

6

87647029

HOSE CLAMP,40-64mm

40 - 64 MM

1шт.

7

218-5062

HYD CONNECTOR,7/8"-14, 37 Degree x 7/8"-14, O-Ring

2шт.

8

84403324

RUBBER SEAL,664mm L

1шт.

9

407962A1

SPACER,9.8mm ID x 12.9mm OD x 11mm L

Zinc Plated

2шт.

10

614-8020

BOLT,Hex, M8 x 1.25 x 20mm

2шт.

11

214-1440

HOSE CLAMP,#40, 2.06" - 3", Type F Worm

1шт.

12

84474837

RADIATOR HOSE

Lower

1шт.

13

87301356

RIVET,Pop, 3/16" x .700"

1шт.

14

614-8040

BOLT,Hex, M8 x 1.25 x 40mm, Cl 8.8, Full Thd

1шт.

15

515-22254

CLAMP,1", Insul, 5/16" Bolt

1шт.

16

87418360

SPACER,9.8mm ID x 16mm OD x 16mm W

8MM X 16MM

1шт.

17

47615718

SHROUD

Fan

1шт.

18

515-23143

CLAMP,9/16", Insul, 3/8" Bolt

1шт.

19

84329358

RADIATOR HOSE

Upper

1шт.

20

214-1416

HOSE CLAMP,#16, 0.81" - 1.5", Type F Worm

4шт.

21

87454376

HOSE,25mm ID, 29.95mm OD, 90 Degree

Deaeration End

1шт.

22

47540340

TUBE

Deaeration

1шт.

23

47428712

TUBE

Left Hand Upper Cooler

1шт.

24

214-1412

HOSE CLAMP,#12, 0.69" - 1.25", Type F Worm

2шт.

25

84540367

SEAL,614mm L

Lower Radiator

1шт.

26

87446082

RETAINING PLATE,390mm x 195mm x 43mm L

Left Hand Lower Shroud

1шт.

27

47428711

TUBE

Left Hand Lower Cooler

1шт.

28

L11541

CABLE TIE,203.2mm L, Nylon

7 - 8 Inch Black

3шт.

29

87301355

RIVET,Pop, 3/16" x .575"

6шт.

30

806-8016

BOLT,Hex, M8 x 1.25 x 16mm, Cl 10.9

4шт.

31

87367622

HOSE,25.40 mm ID x 60.00 mm, SAE 20R3 CLASS D-1 Or D-2

Tank to Tube

1шт.

32

87616934

HOSE,6.35mm ID x 750mm L, SAE 30R6

Overflow

1шт.

33

515-22127

CLAMP,1/2", Insul, 5/16" Bolt

1шт.

34

84387349

BRACKET

Bottle Retaining, Left Hand

1шт.

35

87674844

RESERVOIR, COOLANT E,3L

Bottle Assembly, Incl 38

1шт.

36

84387348

BRACKET

Bottle Retaining, Right Hand

1шт.

37

84387496

BRACKET

Right Hand CAC Tube Support

1шт.

38

85803019

RADIATOR CAP

Coolant Tank

1шт.

39

47565514

SEAL,664mm L

1шт.

40

47369249

SEAL,615.7mm L

1шт.
