Запчасти Case 586H (23.314.AH[02]) - VAR - 745136 - 4WD DRIVE SHAFT GUARD (23) - FOUR WHEEL DRIVE SYSTEM

1

47604689

GUARD

Drive Shaft, Years: -01-APR-17

1шт.

1

48079595

GUARD

Drive Shaft, Start Year: 01-APR-17

1шт.

2

86625256

WASHER,13.3mm ID x 28.5mm OD x 4mm Thk

3шт.

3

614-12040

BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd

3шт.

4

47654986

CONSTRUCTION DIA

DIA Kit, 4WD Drive Shaft, Incl 1 - 3, Years: -01-APR-17

1шт.

4

48099553

DIA Kit, 4WD Drive Shaft, Incl 1 - 3, Start Year: 01-APR-17

KIT

1шт.

To See the Full DIA Kit Composition Look For All the Figures Where the DIA Kit P/N is Shown

1шт.
