Запчасти Case 588G (06-50) - AXLE, FRONT - MOUNTING (06) - POWER TRAIN

1

279172A1

AXLE, REAR

AXLE REAR Front Drive, See Figure 06-53 - 06-57, 07-01 - 07-02, No Longer Available, Order 319063A1

1шт.

1

87422526R

REMAN-REAR AXLE

585G, 586G, 588G, Reman For New P/N's 279172A1, 319063A1, 87422526

1шт.

1

87422526C

CORE-REAR AXLE

Return Part Number

1шт.

1

319063A1

AXLE, REAR

AXLE REAR Front Drive, With Oil Temperature Switch, See Figure 06-58 - 06-62, 07-03, 07-04, If Used

1шт.

1

87422526R

REMAN-REAR AXLE

585G, 586G, 588G, Reman For New P/N's 279172A1, 319063A1, 87422526,

1шт.

1

87422526C

CORE-REAR AXLE

Return Part Number

1шт.

1

384952A1

AXLE, REAR

AXLE REAR Front Drive, With Oil Temperature Sender, See Figure 06-63 - 06-67, 07-05, 07-06, Two Spider Differential; If Used

1шт.

1

87422891

AXLE, REAR

AXLE REAR Front Drive, With Oil Temperature Sender, See Figure 06-63 - 06-67, 07-05, 07-06, Four Spider Differential; If Used

1шт.

1

87422891R

REMAN-REAR AXLE

Remanufactured, 87422891 Axle

1шт.

1

87422891C

CORE-REAR AXLE

Return Part Number 87422891 Axle, Core, Use This Part Number To Return Core For Credit When Using A Remanufactured Assembly

1шт.

1

384952A1R

REMAN-AXLE

Reman For New P/N 87422891

1шт.

1

384952A1C

CORE-AXLE

Return Part Number Four Spider Differential

1шт.

2

D138492

NUT,M22 X 1.5 - 6 HVY HEX

22 mm

20шт.

3

87313544

WASHER,22mm ID x 44mm OD x 5 mm Thk

22.52 ID x 44.0 OD x 5.0 mm thk, Hardened; Replaces D138380 22.80 ID x 44.5 OD x 5.56 mm thk Hardened Washer Used On Some Models

20шт.

4

827-20230

BOLT,Hex, M20 x 2.5 x 230mm, Cl 10.9

8шт.

5

896-11020

WASHER,22mm ID x 37mm OD x 4mm Thk

16шт.

6

117933A1

LARGE PLATE

PLATE, LARGE Mounting

2шт.

7

829-1420

NUT,M20, Cl 10

8шт.
