Запчасти Case 586D (172) - REAR DRIVE AXLE MOUNTING AND DRIVE SHAFT, FOUR WHEEL DRIVE MODELS (27) - REAR AXLE SYSTEM

1

REF

INSTRUCTION

DRIVE SHAFT - rear wheel drive, parts list Figure 175

1шт.

2

28-724

BOLT,Hex, 7/16" - 20 x 1-1/2", Gr 8

- hex head, 7/16" - 20 NF x 1-1/2", grade 8

4шт.

3

232-4617

LOCK NUT,7/16"-20, GC

NUT - hex, self-locking, 7/16" - 20 NF

4шт.

4

D125602

GUARD

- drive shaft

1шт.

5

113-924

BOLT,Hex, 1" - 8 x 2-1/2", Gr 5, Full Thd

4шт.

6

131-20

LOCK NUT,1"-8, GB

NUT - hex, self-locking, 1-1/8" - 7 NC

4шт.

7

D124605

CENTER AXLE

AXLE ASSEMBLY (Carraro 118218) - rear drive, parts list Figures 176-184

1шт.

D126549

KIT

- bearing cap, replaces production axle caps, must order two kits, Includes: Ref. 8 - 11

1шт.

8

NSS

NOT SOLD SEPARAT

CAP - axle mounting, rear

1шт.

9

D126551

SHIM,0.3mm Thk

Cap 0.3mm Thk

1шт.

10

D126552

SHIM,0.4mm Thk

Cap 0.4mm Thk

1шт.

11

D126553

SHIM,0.5mm Thk

Cap 0.5mm Thk

1шт.

12

26-1256

BOLT,Hex, 3/4" - 10 x 3-1/2", Gr 8

- hex head, 3/4" - 10 NC x 3-1/2", grade 8

4шт.

13

D34666

WASHER,33.34mm ID x 63.5mm OD x 2.38mm Thk

- 3/4", hardened

4шт.

14

219-1

LUBE NIPPLE,1/8" - 27 NPTF

GREASE FITTING - straight, 1/8" NPT

2шт.

15

D93588

FITTING

ADAPTER - grease fitting

2шт.

16

192-23

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

2шт.
