Запчасти Case 584D (310) - 21-1/2 FOOT (6.5 M) MAST FOR 584D (83) - TELESCOPIC SINGLE ARM
№
Артикул
Название
Примечание
Количество
D121916
MAST ASSEMBLY
MAST - complete, machinery item, see Figure 2 for ordering, Includes: Ref. 1 - 47
1шт.
1
D88745
LARGE PLATE
PLATE - trunnion bar ends
4шт.
2
113-177
BOLT,Hex, 5/16" - 18 x 3", Gr 5
8шт.
3
131-4
LOCK NUT,5/16"-18, GB
NUT - hex, self-locking, 1/2" - 13 NC
8шт.
4
D75934
BAR
- trunnion
1шт.
5
D40841
LARGE PLATE
WEAR PLATE - horizontal
4шт.
6
D40840
LARGE PLATE
WEAR PLATE - vertical
4шт.
7
D73662
FRAME
- outer, Includes: Ref. 8 - 11
1шт.
8
D40843
BUSHING,25.4mm ID x 38.1mm OD x 24.38mm L
BEARING - self-aligning
3шт.
9
D32555
PAD
WEAR PLATE - 1/8" (3 mm) x 5" (127 mm)
2шт.
10
D27363
WEAR PAD
WEAR PLATE - 3/16" (5 mm) x 6" (152 mm)
4шт.
11
D47895
WEAR PAD
WEAR PLATE - 5/16" (8 mm) x 4-1/2" (114 mm)
2шт.
12
113-436
BOLT,Hex, 1/2" - 13 x 5-1/2", Gr 5
1шт.
14
N7643
CYLINDER
- lift, parts list Figure 296
1шт.
15
165-166
HEX SOC SCREW,Prev Torque, 1/2" - 20 x 2"
BOLT - hex socket head, self-locking, 1/2" - 20 NF x 2"
2шт.
16
192-23
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
2шт.
17
D73664
CHANNEL
FRAME - center, Includes: Ref. 18 - 21
1шт.
18
D27362
WEAR PAD
WEAR PLATE - 1/8" (3 mm) x 10" (254 mm)
2шт.
19
D27365
PAD
WEAR PLATE - 3/16" (5 mm) x 10" (254 mm)
4шт.
20
D27364
WEAR PAD
WEAR PLATE - 1/8" (3 mm) x 6" (152 mm)
4шт.
21
D32555
PAD
WEAR PLATE - 1/8" (3 mm) x 5" (127 mm)
2шт.
22
D73663
FRAME
- inner, Includes: Ref. 23
1шт.
23
60972
STRIP
WEAR PLATE - 1/8" (3 mm) x 11" (279 mm)
6шт.
24
25-1512
JAM NUT,Jam, 3/4"-10, G5
- hex, jam, 3/4" - 16 NF, outer chain bolt
2шт.
24
129-170
JAM NUT,Jam, 1"-14, G5
Inner chain bolt Jam, 1"-14, G5
2шт.
25
129-130
NUT,1"-14, G5
- hex, 1" - 14 NF, plated, inner chain bolt
2шт.
26
N6877
BOLT
- inner chain
2шт.
(N6011 includes the N6010 Link)
1шт.
27
N6010
LINK,50.749mm Pitch
- connecting, outer chain, Includes: Ref. 28
4шт.
27
N6878
CHAIN LINK
LINK - connecting, inner chain, Includes: Ref. 28
4шт.
28
132-45
COTTER PIN,1/8" x 5/8"
Pin, Split (Cotter), , N6010 and N6878 links 1/8" x 5/8"
2шт.
29
D73665
CHAIN (AG)
CHAIN - inner, 95 links
2шт.
29
D34446
CHAIN
- outer, 113 links
2шт.
30
132-99
COTTER PIN,3/16" x 2"
Pin, Split (Cotter), , D87070 pin 3/16" x 2"
2шт.
30
132-102
COTTER PIN,3/16" x 2 1/2"
Pin, Split (Cotter), , N7324 pin 3/16" x 2 1/2"
2шт.
31
D87070
PIN
- outer, service, includes grease fitting not required, Includes: Ref. 32
2шт.
31
N7324
KIT
PIN - inner guide wheel, service, includes grease fitting not required, Includes: Ref. 32
2шт.
32
211-5
BALL,3/16" Dia
- 3/16", grade 200, chrome alloy steel, D87070 and N7324 pins, if used, not shown
1шт.
33
60944
THRUST WASHER
THRUST WASHER - outer guide wheel
4шт.
33
D36582
WASHER
THRUST WASHER - inner guide wheel
4шт.
34
D87069
SPROCKET ASSY.
WHEEL - outer, sealed
2шт.
34
D39482
SUPPORT,1.75" ID x 4.3" OD x 1.51"
WHEEL - guide, inner chain
2шт.
35
61-832
HEX SOC SCREW,1/2"-13 x 2"
BOLT - hex socket head, 1/2" - 13 NC x 2"
16шт.
36
129-145
JAM NUT,Jam, 1/2"-13, G5
16шт.
37
D47875
LARGE PLATE
BACK PLATE - upper
1шт.
39
D47876
LARGE PLATE
BACK PLATE - lower
1шт.
40
D47877
SHEET
CARRIAGE ASSEMBLY - right-hand, includes (2) N7958 wear plates
1шт.
Carriages must be aligned and drilled at time of installation.
1шт.
41
D47878
SUPPORT ASSY.
CARRIAGE ASSEMBLY - left-hand, includes (2) N7958 wear plates
1шт.
Carriages must be aligned and drilled at time of installation.
1шт.
42
129-145
JAM NUT,Jam, 1/2"-13, G5
4шт.
43
178-693
SET SCREW,Hex Soc, 1/2"-13 x 3"
- hex socket headless, 1/2" - 13 NC x 3", oval point
4шт.
44
D86604
AXLE
PIN - roller, service, includes grease fitting not required, Includes: Ref. 45
4шт.
45
211-5
BALL,3/16" Dia
- 3/16", grade 200, chrome alloy steel, if used, not shown
1шт.
46
D47894
ROLLER BEARING,25.39mm ID x 63.5mm OD x 32.26mm W
ROLLER - load
4шт.
47
60917
THRUST WASHER
THRUST WASHER - roller
8шт.
Выбрано товаров: 59
