Артикул
Название
Примечание
Количество
1
D52962
GUARD - overhead
1шт.
2
113-426
BOLT,Hex, 1/2" - 13 x 2-3/4", Gr 5
Hex, 1/2"-13 x 2 3/4", G5
6шт.
3
192-23
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
6шт.
4
129-105
NUT,Hex, 1/2" - 13, Gr 5
6шт.
5
D52955
SUPPORT - overhead guard, front
2шт.
6
113-424
BOLT,Hex, 1/2" - 13 x 1", Gr 5, Full Thd
2шт.
7
192-23
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
2шт.
8
129-105
NUT,Hex, 1/2" - 13, Gr 5
2шт.
9
D52958
SUPPORT - overhead guard, R.H. rear
1шт.
10
D52957
SUPPORT - overhead guards, L.H. rear
1шт.
11
113-607
BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 5, Full Thd
4шт.
12
192-25
LOCK WASHER,5/8"
WASHER, LOCK, 5/8"
4шт.
13
195-108
WASHER,5/8"
- plain () 5/8"
4шт.
D55381
SEAT
ASSEMBLY - operator's (Identified by pleated seat and backrest cushion) When stock is exhausted, order D58271 seat assembly for service, listed on Figure 59D, Includes: Ref. 14 - 23
1шт.
14
D55938
CUSHION
- backrest
1шт.
15
D55939
CUSHION
- seat
1шт.
16
193-545
SCREW,SEMS, Hex Hd, 1/4"-20 x 3/4"
AND WASHER ASSY. - hex. head (1/4" - 20 NC x 3/4") Cushion to seat shell
5шт.
17
D55940
SHELL
- seat
1шт.
18
131-31
LOCK NUT,5/16"-24, G8
NUT - hex., lock (5/16" - 24 NF)
4шт.
19
95-5
WASHER,3/8" x 7/8" x .083"
- standard wrot (5/16")
8шт.
20
114-101
BOLT,Hex, 5/16" - 24 x 7/8", Gr 5, Full Thd
(Slide to shell) Hex, 5/16"-24 x 7/8", G5, Full Thd
4шт.
21
D53344
SPRING
- adjustment lever
1шт.
22
D53585
CUSHION
SLIDE - seat, R.H. (Adjustment side)
1шт.
23
D53586
SLIDE
- seat, L.H. (Plain side)
1шт.
24
25-115
NUT,5/16"-24, G5
- hex (5/16"-24 NF)
4шт.
25
92-5
LOCK WASHER,5/16"
4шт.
26
D52809
BASE PLATE - seat mounting
1шт.
28
192-21
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
4шт.
29
195-525
WASHER,3/8", SAE
- plain (3/8") Zinc plated
4шт.
A59450
WARNING SIGN
EMBLEM AND BACKING PLATE ASSEMBLY - slow moving vehicle, Includes: Ref. 30 and 31
1шт.
30
321-1751
DECAL
- slow moving vehicle emblem
1шт.
31
NSS
NOT SOLD SEPARAT
BACKING PLATE - slow moving vehicle emblem (Not shown)
1шт.
32
187-329
SELF-TAP SCREW,Pan, 0.19"-16 x 1/4"
SCREW - self tapping, pan head (#10 x 1/2") Not shown
2шт.
Выбрано товаров: 34
