Запчасти Case 584C (094) - TRACTOR LAMPS, D88684 FRONT LAMP ASSEMBLY (55) - ELECTRICAL SYSTEMS

D88684

LAMP

FRONT LAMP ASSEMBLY - interchangeable with D49976, Includes: Ref. 1 - 6A

2шт.

1

NSS

NOT SOLD SEPARAT

SHELL - lamp, accepts Ref. 2 only

1шт.

1a

NSS

NOT SOLD SEPARAT

SHELL - lamp, accepts Ref. 2A only

1шт.

2

A25213

RETAINER

- lamp, rubber, locks to shell with three rubber tabs, if used

1шт.

2a

N6160

LAMP

RETAINER - lamp, rubber, locks over shell flange, if used

1шт.

3

A11280

LAMP

BULB - sealed beam, No. 4411

1шт.

4

D37048

BUSHING

- pivot

1шт.

5

193-87

LOCK WASHER,Ext-Int Tooth, 1/2"

WASHER, LOCK, , If used Ext-Int Tooth, 1/2"

1шт.

5a

192-23

LOCK WASHER,1/2"

WASHER, LOCK, , If used 1/2"

1шт.

6

131-9

LOCK NUT,Prev Torque, Hex, 1/2" - 20, Gr B

NUT - hex, self-locking, 1/2" - 20 NF, if used

1шт.

6a

129-165

JAM NUT,Jam, 1/2"-20, G5

If used Jam, 1/2"-20, G5

1шт.

7

95-8

WASHER,1/2"

flat, if used 1/2"

2шт.
