Запчасти Case 584C (090) - FRONT AND REAR LAMPS AND CONNECTIONS (55) - ELECTRICAL SYSTEMS

1

REF

INSTRUCTION

LAMP ASSEMBLY - front, parts list Figure 94

2шт.

2

D49733

LAMP

ASSEMBLY - stop and tail, if used, parts list Figure 92

2шт.

3

D49734

LAMP

ASSEMBLY - signal and flasher, if used, parts list Figure 92

2шт.

4

D58713

LARGE PLATE

BRACKET - center, lamp mounting, if used

2шт.

5

13-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

2шт.

6

92-6

LOCK WASHER,3/8"

2шт.

7

25-106

NUT,3/8"-16, G5

- hex, 3/8" - 16 NC

2шт.

8

D58721

BRACKET

- outer, lamp mounting, if used

2шт.

9

13-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

10шт.

10

92-6

LOCK WASHER,3/8"

10шт.

11

25-106

NUT,3/8"-16, G5

- hex, 3/8" - 16 NC

10шт.

12

D56401

ELECTRICAL WIRE

WIRE - rear lamps

1шт.

13

A11768

ELECTRICAL WIRE

WIRE - rear lamps, ground

2шт.

14

D57287

RETAINER

- rubber, rear lamp, no longer used, order D93241 retainer

2шт.

14

D93241

RETAINER

- rubber, rear lamp

2шт.

15

D33182

LAMP

BULB - rear, sealed beam, No. 4410, no longer used, order A42294 bulb

2шт.

15

A42294

SEALED BEAM UNIT

BULB - rear, sealed beam, No. 4406

2шт.

16

182-516

SCREW,Sl Pan Hd, #10 - 24 x 1/2"

- pan head, slotted, No. 10 - 24 NC x 1/2"

6шт.

17

D57288

RING

- metal, lamp retainer

2шт.

18

192-18

LOCK WASHER,Helical Spring, #10, 0.196" ID, CST, ZND

WASHER, LOCK, #10

6шт.

19

129-17

NUT,Hex, #10 - 24

NUT - hex, No. 10 - 24 NC

6шт.

20

95-8

WASHER,1/2"

flat, if used 1/2"

2шт.
