Запчасти Case 21F (41.216.AT[01]) - STEERING CYLINDER, ARTICULATION (41) - STEERING

1

47679902

STEERING CYLINDER

ASSY

1шт.

2

419819A1

WASHER

2шт.

3

380583A2

PIN

, Years: -20-SEP-15

1шт.

3

47861067

PIN

, Start Year: 21-SEP-15

1шт.

4

87308853

HEX SOC SCREW,M8 x 96.4mm, Cl 12.9

1шт.

5

832-10408

NUT,M8 x 1.25, Cl 8.8

1шт.

6

219-1

LUBE NIPPLE,1/8" - 27 NPTF

1шт.

7

8501088

WASHER,41mm ID x 76mm OD x 1.59mm Thk

2шт.

8

47576881

PIN

1шт.

9

L125100

SPACER,17.48mm ID x 31.75mm OD x 14.3mm Thk

1шт.

10

496-81025

WASHER,21/32" x 2 1/2" x .188", HDN

1шт.

11

627-16035

BOLT,Hex, M16 x 2 x 35mm, Cl 10.9, Full Thd

1шт.

12

380602A1

BUSHING

1шт.

13

9992305

HYD CONNECTOR,13/16" - 16 ORFS x 3/4" - 16 ORB

ASSY, Incl 14 (Qty 1), 15 (Qty 1), 16 (Qty 1)

2шт.

14

NSS

NOT SOLD SEPARAT

Connector, Incl in 13

2шт.

15

128825

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

2шт.

16

9992298

O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro

2шт.
