Запчасти Case 321E (02.019[2988857000]) - SWING AXLE INSTALLATION (27) - REAR AXLE SYSTEM

1

Swing Axle Mounting Parts Standard (4552435), See Fig 02.020

1шт.

2

1527327

LUBE NIPPLE

Replaces 420381A1

1шт.

3

2813370

SOCKET

Replaces 423934A1

1шт.

4

1768453

HYD CONNECTOR

Replaces 420267A1

2шт.

5

2292104

HYDRAULIC HOSE,M5 x 1100

Replaces 420471A1

1шт.

6

2292108

HYDRAULIC HOSE,M5 x 1400

Replaces 420474A1

1шт.
