(02.102[2991193000]) - AXLES ASSEMBLY SET FAST GEAR 35KM/H

Запчасти Case 321E (02.102[2991193000]) - AXLES ASSEMBLY SET FAST GEAR 35KM/H (23) - FOUR WHEEL DRIVE SYSTEM

Схема запчастей Case 321E - (02.102[2991193000]) - AXLES ASSEMBLY SET FAST GEAR 35KM/H (23) - FOUR WHEEL DRIVE SYSTEM
11
1
5
10
1
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

Axles Fast Gear Complete, (2840201) See Fig 02.105

1шт.

5

Hydraulic System Axles, (2840230) See Fig 20.005

1шт.

10

Electrical System Operators Cab Fast Gear, (3004958) See Fig 32.502

1шт.

11

87657622

DASHBOARD

See Fig 32.407

1шт.
