Запчасти Case 121E (0.34.9) - BELT PULLEY DRIVE & COVER (01) - ENGINE

1

504255373

BRACKET, SUPPORTING

- ASSY

1шт.

2

4892732

BALL BEARING,34mm ID x 64mm OD x 37mm W

1шт.

3

4890732

RETAINER,11.50mm ID x 52mm OD x 7mm

1шт.

4

2852171

SNAP RING

1шт.

5

2854424

SCREW,Hex, Flg Hd, M10 x 1.5 x 70mm

M10 x 70

1шт.

6

2852247

BOLT,Hex, M8 x 1.25 x 30mm

M8X30

5шт.

7

504255370

PULLEY,157.4mm OD x 65mm W

1шт.

8

2853674

SCREW,Hex, Flg Hd, M10 x 1.5 x 20mm

M10 x 20

4шт.
