(02.017[2988905000]) - REAR AXLE MOUNTING PARTS SELF-LOCKING 20 KM/H

Запчасти Case 121E (02.017[2988905000]) - REAR AXLE MOUNTING PARTS SELF-LOCKING 20 KM/H (27) - REAR AXLE SYSTEM

Схема запчастей Case 121E - (02.017[2988905000]) - REAR AXLE MOUNTING PARTS SELF-LOCKING 20 KM/H (27) - REAR AXLE SYSTEM
3
1
2
4
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

Swing Axle Self-Locking, (4552466) See Fig 02.023

1шт.

2

4550966

HYDRAULIC MOTOR

See Fig 22.120

1шт.

3

2978362

O-RING

134 x 3 mm

1шт.

4

864-12040

HEX SOC SCREW,M12 x 40mm, Cl 8.8

4шт.
