Запчасти Case 321D (27.420[001]) - LIQUEFIER INSTALLATION (OPTION) (S/N 591073-UP) No Description

1

NS

NOT SERVICED

SEE FIGURE 27.421/001

1шт.

12

424298A1

HOSE

1шт.

21

423983A1

RECEIVER-DRYER

1шт.

22

423984A1

BRACKET

1шт.

23

423985A1

BRACKET

1шт.

30

614-8025

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd

1шт.

31

895-15008

WASHER,9mm ID x 20mm OD x 1.6mm Thk

2шт.

32

43362

NUT,M8 x 1.25, Cl 10

1шт.

101

424299A1

1шт.

201

423982A1

1шт.

202

424300A1

HOSE PROTECTION

1шт.
