(02.024[2988914000]) - REAR AXLE INSTALLATION SELF-LOCKING

Запчасти Case 321D (02.024[2988914000]) - REAR AXLE INSTALLATION SELF-LOCKING (27) - REAR AXLE SYSTEM

Схема запчастей Case 321D - (02.024[2988914000]) - REAR AXLE INSTALLATION SELF-LOCKING (27) - REAR AXLE SYSTEM
6
3
5
4
4
1
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

Rear Axle Mounting Parts Self-Locking (45524441), See Fig 02.025

1шт.

2

1527327

LUBE NIPPLE

9S20K-A3B, Replaces 420381A1

1шт.

3

2813370

SOCKET

GE15-LM-ED/OMD, Replaces 423934A1

1шт.

4

1768453

HYD CONNECTOR

SOCKET DIN 3901-L 6 E-M-ST, Replaces 420267A1

2шт.

5

2292104

HYDRAULIC HOSE,M5 x 1100

Replaces 420471A1

1шт.

6

2292108

HYDRAULIC HOSE,M5 x 1400

Replaces 420474A1

1шт.

Выбрано товаров: 6
