Запчасти Case 221D (02.115[001]) - CAMSHAFT DRIVE FAST GEAR FRONT (OPTION) (S/N 581101-UP) (25) - FRONT AXLE SYSTEM

1

NS

NOT SERVICED

SEE FIGURE 16.610/004

1шт.

70

420300A1

TAPERED BEARING

2шт.

71

420301A1

SPACER, RING

1шт.

72

420302A1

SPACER, RING

1шт.

73

420303A1

SPACER, RING

1шт.

110

3132726R91

BEARING

1шт.

113

3132726R91

BEARING

1шт.

114

420305A1

NUT

1шт.

115

420306A1

SPACER, RING

1шт.

116

420307A1

SPACER, RING

1шт.

117

420308A1

SPACER, RING

1шт.

120

420309A1

SPACER, RING

1шт.

121

420310A1

SPACER, RING

1шт.

122

420311A1

SPACER, RING

1шт.

130

420312A1

BUSHING

1шт.

131

420313A1

BUSHING

1шт.

132

420314A1

BUSHING

1шт.

133

420315A1

BUSHING

1шт.

200

420316A1

HOUSING

1шт.

201

933799R1

PLUG,Hex Soc, M24 x 1.5

1шт.

202

A48812

SEALING RING,M24 x 29 x 1.5

2шт.

210

420317A1

PLUG

1шт.

300

420318A1

FLANGE

1шт.

302

420319A1

SEAL

1шт.

450

NS

NOT SERVICED

SEE FIGURE 19.202/003

1шт.

451

NS

NOT SERVICED

SEE FIGURE 19.202/004

1шт.

452

420323A1

O-RING

2шт.
