Запчасти Case TV380 (88.055.05) - DIA KIT, ROAD LIGHT LG VERT CASE (88) - ACCESSORIES

1

47999846

KIT

Incl 2-40

1шт.

2

48000294

INSTRUCTION

Instulation

1шт.

3

131691A1

ROCKER SWITCH

Front& Rear Coupler

1шт.

4

280476

SELF-TAP SCREW,HWH, 3/8"-16 x 1"

1шт.

5

47821007

WIRE HARNESS

Rear Road Jumper

4шт.

6

47870827

BRACKET

Road Lights

1шт.

7

47972152

JUMPER

Harness Wire, Flasher

2шт.

8

47972154

JUMPER

Harness Wire, Pressure Switch

1шт.

9

84155716

PRESSURE SWITCH

2шт.

10

84263153

SWITCH

Rocker, Loader Lockout

1шт.

11

84306583

BRACKET

LH, Light

1шт.

12

84306585

BRACKET

RH, Light

1шт.

13

84416164

FOAM INSULATION

Upper Chassis

2шт.

14

84420530

WIRE HARNESS

LH, Boom

1шт.

15

84423502

WIRE HARNESS

Boom Lamp

1шт.

16

84467699

CLAMP,25.4mm, Insulated, 8.7mm Bolt Hole - P Type

Insulated

1шт.

17

84522291

CLAMP,19mm, Insulated, 8.7mm Bolt Hole - P Type

Insulated

1шт.

18

86502967

SCREW,Phillips Drive, Pan HD, M5 x 30mm, Cl 4.8

8шт.

19

86505868

SERRATED NUT,Hex, M8 x 1.25, Cl 8

4шт.

20

86512420

CARRIAGE BOLT,Rnd Head, M8 x 1.25 x 20mm, Full Thd, Cl 8.8

4шт.

21

86512495

FLANGE NUT,Hex, M5, Cl 8

8шт.

22

86589143

SPACER,9.5mm ID x 15.9mm OD x 12.7mm L

2шт.

23

86598598

CLAMP,19mm, Insulated, 13.5mm Bolt Hole - P Type

2шт.

24

86604657

INDICATOR, TURN SIGN

1шт.

25

86625035

CLAMP,12.7mm, Coat, 7.1mm Bolt Hole, P Type

Insulated

2шт.

26

86637977

CLAMP,25.4mm, Coat, 8.7mm Bolt Hole, P Type

Insulated

2шт.

27

86639241

NUT,Prev Torque, M5 x 0.8, Cl 8

1шт.

28

86639263

BOLT,Hex, M5, Cl 8

1шт.

29

87015934

BOLT,Hvy Hex Flange , M8 x 35mm, Cl 8.8

2шт.

30

87029955

CLAMP,22.2mm, Coat, 10.3mm Bolt Hole, P Type

Insulated

2шт.

31

87572859

LAMP

Combination Right

1шт.

32

87572860

LAMP

Combination Leeft

1шт.

33

87627854

LIGHT ASSY.,12V, 27W, Red

Tail/Stop

2шт.

34

87629587

LIGHT ASSY.,12V, 27W, Amber

Turn/SMV

2шт.

35

87634133

SWITCH

Rocker, Hazard Lights

1шт.

36

87668737

CABLE TIE,203.2mm L, Nylon, Black

5шт.

37

9804258

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

2шт.

38

9804277

FLANGE NUT,Hex, M8 x 1.25, Cl 8

4шт.

39

9821783

FLASHER UNIT

1шт.

40

L11541

CABLE TIE,203.2mm L, Nylon

4шт.
