(55.050.010) - HVAC SYSTEM, DUCT ASSY

Запчасти Case TV380 (55.050.010) - HVAC SYSTEM, DUCT ASSY (50) - CAB CLIMATE CONTROL

Схема запчастей Case TV380 - (55.050.010) - HVAC SYSTEM, DUCT ASSY (50) - CAB CLIMATE CONTROL
50.200.030
1
3
4
2
50.200.030
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

47929817

WIRE HARNESS

Incl Ref 2 - 4

1шт.

2

87688788

MULTIPOLE CONNECTOR,Male, 2 Pole

HVAC High Pressure Switch, X-76

1шт.

3

87693745

ELEC CONNECTOR,Male, Blade

A/C Compressor

1шт.

4

87382910

WIRE CONNECTOR,Female, 3 Cavities

Chassis Harness/ HVAC Engine Interconnect, X-75

1шт.

Connects to Chassis Harness

1шт.
