Запчасти Case TV380 (29.200.AI[04]) - ELECTRONIC CONTROLS, HANDLE MOUNTING (29) - HYDROSTATIC DRIVE

1

9804256

BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8

4шт.

2

47544570

IMPORTANT DECAL

EZ EH Operation

1шт.

3

47619265

PLATE

247.2mm L, Heel Cover

1шт.

4

47710379

SCREW,Pan Head, M5 x 0.8, Full Thd, Cl 4.8

4шт.

5

84322854

FOAM INSULATION,684mm L x 6mm W x 3mm Thk

684mm L, Sealing Strip

1шт.

6

86512497

FLANGE NUT,M12 x 1.75, Cl 10

1шт.

7

86588450

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

4шт.

8

86598598

CLAMP,19mm, Insulated, 13.5mm Bolt Hole - P Type

1шт.
